Nickel-Iron Soft Magnetic Alloys
USD $25 - $150
/ Kilogram
100 Kilograms(Min.Order)
- 500 Metric Ton / Metric Tons per Month
- Shanghai
- T/T
You May Like
Product Details
| Brand Name | Brilliance | Place of Origin | China | |
| Model Number | BL-0056 | Type | Nickel Wire | |
| Application | Electronics | Powder Or Not | Not Powder | |
| Ni (Min) | 45% |
Product Description
Fe-Ni Soft Magnetic Alloy （GBn198-1988）
| Sort | Grade | Composition | International Similar Grade | |||
| IEC | Russia | U.S.A. | ||||
| High initial permeability of soft magnetic alloy | 1J79 | Ni79Mo4 | E11c | 79НМ | Mumeta 4-79 Permalloy Supermalloy | |
| 1J85 | Ni80Mo5 | E11c | 79НМА | |||
| High magnetic conductivity higher saturation magnetic flux density soft magnetic alloy | 1J46 | Ni46 | E11e | 46Н | 45-Permalloy | |
| 1J50 | Ni50 | E11a | 50Н | Hy-Ra49 Permalloy | ||
Chemical Composition:
| Grade | ChemicalComposition(%) | ||||||||||
| C | P | S | Mn | Si | Ni | Cr | Co | Mo | Cu | Fe | |
| 1J46 | ≤0.03 | ≤0.02 | ≤0.02 | 0.6-1.1 | 0.15-0.30 | 45-46.5 | - | - | - | ≤0.2 | Balance |
| 1J50 | ≤0.03 | ≤0.02 | ≤0.02 | 0.3-0.6 | 0.15-0.30 | 49-50.5 | - | - | - | ≤0.2 | Balance |
| 1J79 | ≤0.03 | ≤0.02 | ≤0.02 | 0.6-1.1 | 0.30-0.50 | 78.5-81.5 | - | - | 3.8-4.1 | ≤0.2 | Balance |
| 1J85 | ≤0.03 | ≤0.02 | ≤0.02 | 0.3-0.6 | 0.15-0.30 | 79-81 | - | - | 4.8-5.2 | ≤0.2 | Balance |
Mechanical Property :
| Grade | Resisitivity (μΩ•m) | Desinty (g/cm3) | CuriePoint ℃ | HighSaturatedmagneto-strictioncoefficient λθ/10-6 | Brinellhardness HBS | σbTensile Strength MPa | σsYieldStrength MPa | Elongation (%)δ | ||||
| unan- nealed | an- nealed | unan- nealed | an- nealed | unan- nealed | an- nealed | unan- nealed | an- nealed | |||||
| 1J46 | 0.45 | 8.2 | 400 | 25 | 170 | 130 | 735 | 735 | 3 | |||
| 1J50 | 0.45 | 8.2 | 500 | 25 | 170 | 130 | 785 | 450 | 685 | 150 | 3 | 37 |
| 1J79 | 0.55 | 8.6 | 450 | 2 | 210 | 120 | 1030 | 560 | 980 | 150 | 3 | 50 |
| 1J85 | 0.56 | 8.75 | 400 | 0.5 | - | - | - | - | - | - | - | - |
