Guyana Poultry Farming Equipment - A Type Battery Broiler Chicken Cage with Automatic Chicken Manure Clean Machine

A FRAME BATTERY BROILER CHICKEN CAGE SYSTEM

It is designed for open or close house in order to improve the density and get the max land usage of the broiler raising house.the caged broiler can grow faster and easier to control its weight and it also can be fully automatic which equipped with feeding,drinking,manure collection and climate control system.

Broiler cage system advantages:

● raising density per unit area increase 50%-100% compared with flooring system;

● the possibilities of infection diseases caused by manure decrease,thus death rate is minimized because the small quantity birds of chickens raised in each small cage units;

● amount of exercise is small because of the cage,the broiler can grow fast;

● more feed will be saved by max size aluminum zinc plated feed troughs or PVC troughs, the troughs can be chosen as farmer’s favorite;

● convenient for observing growth condition of birds grouping and selection;

● uniformity and health condition are both excellent as there is enough place for birds feeding and drinking,and better effect for epidemic prevention than floor raising;

● this is A frame cage system so the unique center cool system with better ventilation.

Unique cage structure design:

● each unit dimension of the pullet cage is 160*62*42cm,2 cells/unit,with 9 birds per cell,each cell dimension is 80*62*42cm,so each birds can get 551 sq.cm(620 sq.cm. per birds if 8 birds per cell) at least before the 7th weeks.

● bottom net is densely welded together,the plastic cushion which put on the bottom cage mesh can protect the baby chicken feet and make them more comfortable till the broiler harvested by farmers;

● the drinking system can be automatic nipple drinking line and manual feeders and drinkers for first two weeks while the broilers are too small to get water nipple drinkers;the nipple drinkers are stainless steel ones with round or square pipes,it can be fitted with water cups under the nipple;the pipes can be adjusted in higher level as the broilers growing bigger day by day because the grid meshes has empty design in the middle place to adjust the pipes going up to higher level;

● the feed troughs has adjust board to get different height during different growing period.

the adjust board is fitted with cages above the trough inside part,it can be PVC or steel ones which chosen by farmers;

● the 1st--2nd tier of cages can be fitted with manure curtain on the back of the cage meshes in case of the dropping manure from upper tiers.

● either open house in tropic countries,or the closed house in temperate area can choose the A frame broiler cage system.
