High Capacity Industrial Plastic Pvc Bag Crusher
- Jiangmen/Guangzhou/Shenzhen
- T/T Credit Card
You May Like
Product Details
| Brand Name | XIECHENG | Place of Origin | Guangdong, China | |
| Use | Waste Plastic Crusher | Certification | CE | |
| Weight | 1800KG | Dimension(L*W*H) | 1570*1320*2000mm | |
| Voltage | 380V/50Hz/3phase as usual | Power | 22/30KW | |
| Condition | New | Power(W) | 22000/30000W | |
| Capacity | 420-680KG/H | Shaft Design | Single |
Product Description
high capacity industrial plastic pvc bag crusher
Optimized with full-closed soundproof structure, it ensures the low noise level under operation.
Equipped with current relay, motor overload protector and multiple safety devices, to ensure safe operation.
The cutters are made of high quality steel featuring wearability and high rigidity.
Dust cyclone separator can effectively remove the air from regrind and facilitates material collecting.
The optional dust collector makes easy cleaning and deduce the pollution caused.
Conveying system is optional to enhance efficiency of feeding.
Granulators up from 30HP are applied with chamber cooling, which can lower the chamber temperature and prevent material from melting-up.
XC-GJ500(11KW or over) is applied with a booster cylinder to assist the opening and closing of the hopper. It's man-power saving.
The Cyclone dust separator is optional.
Within 400 installed wheel,above 500 installed rubber anti vibration mounts,can reduce vibration when machine is working
Model | XC-GP230-SP | XC-GP300-SP | XC-GP400-SP | XC-GP500-SP | XC-GP600-SP | XC-GP800-SP | XC-GP960-SP | |
grinding chamber (mm) | 230*200 | 310*200 | 410*240 | 510*300 | 610*330 | 815*470 | 960*610 | |
grinding capacity (kg/h) | 100-150 | 150-200 | 200-250 | 300-350 | 350-450 | 450-600 | 800-1000 | |
stationary cutter | 2 | 2 | 2 | 2 | 4 | 4 | 4 | |
rotary cutter | 6 | 9 | 12 | 15 | 18 | 24 | 30 | |
power | KW | 4 | 5.5 | 7.5 | 11 | 15 | 22/30 | 37/45/57 |
HP | 5 | 7.5 | 10 | 15 | 20 | 30/40 | 50/60/75 | |
approx. dimension (L×W ×H mm) | 890*640*1145 | 1010*715*1300 | 110*815*1330 | 1290*975*1670 | 1290*1075*1740 | 1735*1525*2180 | 1950*1760*2740 | |
approx. NW(kg) | 290 | 435 | 500 | 900 | 970 | 2000 | 3000 | |
