Industrial Water Cooled Chiller for Extuder Cooling
US$ 6,800 - 7,900
/ Set
1 Set(Min. Order)
- Jiangmen/Guangzhou/Shenzhen
- T/T Credit Card
You May Like
Product Details
| Brand Name | XIECHENG | Place of Origin | Guangdong, China | |
| Certification | CE | |||
| Warranty | 1 year, 1 year | Weight | Customized | |
| Dimension(L*W*H) | 1880*880*1650mm | Condition | New | |
| Voltage | 3PH~220V/380/415V~50HZ/60HZ |
Product Description
Industrial water cooled chiller for extuder cooling
..
Specifications
| Model | UNIT | XC-L10W | XC-L20W | XC-L30W | XC-L40W | XC-L50W |
| Refrigerating Capacity | kw | 30.5 | 61 | 92 | 122 | 122 |
| Kcal/h | 26230 | 52460 | 79120 | 104920 | 104920 | |
| Compressor | Input Power(kw) | 4.5*2 | 9*2 | 27 | 9*4 | 9*4 |
| Rated Power(Hp) | 5*2 | 10*2 | 30 | 10*4 | ||
| Evaporator | Type | *Water Tank with Pipe Coil/ Shell and Tube | ||||
| Pipe Diameter(inch) | 2" | 2.5" | 3" | 3" | 3" | |
| Refrigerant | Type | R407c/R410a/R134a/R404a/R22 | ||||
| Filling Quantity(kg) | 5 | 11 | 12 | 18 | 18 | |
| Cooling Flow(m³/h) | 4.42 | 8.84 | 13.6 | 17.75 | 21.9 | |
| Water Cooled Condenser | Type | *Shell and Tube / Tube in Tube | ||||
| Pipe Diameter(inch) | 2" | 2.5" | 3" | 3" | 3" | |
| Water Tank Capacity(L) | 125 | 350 | 420 | 420 | 420 | |
| Pump | Power(kw) | 0.75 | 1.5 | 2.2 | 4 | 4 |
| Flow(L/min) | 100 | 400 | 400 | 400 | 400 | |
| Safety Protector | high and low pressure protection, overload protection, over temperature protection ,phase sequence protection,etc. | |||||
| Dimension(L*W*H,mm) | 1270*650*1390 | 1870*820*1600 | 1870*820*1600 | 1970*890*1730 | 1970*890*1730 | |
| Operating Weight(kg) | 350 | 800 | 1150 | 1200 | 1380 | |
| "*" means optional or customizable. Capacity based on voltage 380V/50Hz/3Ph. Not all models are showed in above parameters. | ||||||
