China Factory Supply CNC UPVC Window Making Machine
- qingdoao shanghai
- T/T Credit Card
You May Like
-
Cnc Machine for Pvc Windows Upvc Window Door 4 Corner Welding Machine
-
Upvc Window Door Glazing Bead Saw
-
Efficient and Economical Portable Cnc Pvc Window Corner Cleaning Machine
-
Upvc Corner Cleaning Machine Plastic Window Corner Clean Machine
-
Vertical Four Points Vinyl Window Welding Making Machine
-
Pvc Glazing Bead Cutting Machine Plastic Window Door Making Machine
Product Details
| Brand Name | SINON | Model Number | QK04-CNC-120 |
Standard wood packaging
Product Description
PVC window CNC corner cleaning machine
Features:
- Professional used in cleaning the welding tumor in 90°corner of external for window frame and sash, the upper and lower of profile.
- It has multi-function such as vertical milling, saw milling and broaching and so on.
- Two-axis CNC cleaning the corner of processing flow controlling make the operation is easy.
- Adopts industry grade computer system, closed-loop controlling, ensures high precision.
- Interface in figures and diagrams which can display directly the moving trace of the cutter.
- It is simple, direct-viewing with the demonstrating program function, can set two-dimension processing programming by CNC controller
- Equipped with USB connection, may connect with external store..
Optional:
- 5 cutter model, can cleaning groove of rubber strip
Technical Specifications
Input power source | 380V/50Hz |
Total power | 2.0Kw |
Working air pressure | 0.5~0.8MPa |
Air consumption | 200L/min |
Diameter of milling cutter | 200mm |
Principal axis rotate speed | 2800r/min |
Processing profile height | 30~120mm |
Processing profile width | 30~110mm |
Dimension | 2000×1930×1500mm |
Weight | 640kg |
