DEF-FA/30 PLC control double side vibration chamfering machine for short pipe 20mm to 80mm
Main specification
1.Specialized in finish chamfering and trimming surface of the interior/exterior angle of circular tube and round bar end surface once quickly and accurately.
2.The central line of the processing object and the cutter is precise. Specal design and standardization of the blade make adjusting blade easily.
3.Manual nest, automatic feeding, clamping and blade feeding and backing.
4.Only changing the cutter and adjusting the trip holder can make the machie available for different size of the workpiece.
5.Suitable materials: Stainless steel, Steel, Iron, Copper, Aluminum, Nelon, Plastic Pipe and Bar.
6.Processing speed: 3-6 second/piece
Technical parameter
Total Motor Power: 1.5kW
Motor power: 0.75kW*2
Vibration plate power: 150W
Job range: length: 10-100mm, OD: 5-25mm
Machining precision: +/-0.05mm, even chamfer, with 3.2 of roughness
Cycle time: 25-30pcs/minute
Feeding type: vibration plate feeding
Conveying type: motor and pneumatic cylinder
Power head: self made, RPM: 2800r/min
Control: PLC
Frame: welding with tempering
Machine photo
To know more information, please contact us at any time.
