DMCC3H Aluminium Profile CNC Drilling and Milling Machine for Window Door Curtain Wall Processing

Name: DMCC3H Aluminium Profile CNC Drilling and Milling Machine for Window Door Curtain Wall Processing
Brand: PARKER
Availability: InStock

FOB Price

US$ 30,000 - 40,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	PARKER	Place of Origin	Shandong, China
Type	Horizontal	Certification	ISO CE
After-sales Service Provided	Engineers available to service machinery overseas	Warranty	1 Year
Weight	5800KG	Dimension(LWH)	452516301900mm
Voltage	380V/50Hz(optional)	Condition	New
Power(W)	6kw

Product Description

DMCC3H Aluminium profile CNC drilling & milling machine

Introduction

The machine used for processing varieties of holes and slots for diversified aluminum doors and windows It adopts PA control system from Germany Intelligent CNC control system and straightforward human-computer interface make the operation much more convenient and efficient The rotary worktable can change the position among -90,0°and +90°arbitrarily One time clamping can finish milling for three sides.

Advantages

◆ The machine is suitable for processing varieties of holes and slots for diversified aluminum doors and windows.

◆ It adopts high-precision linear guide pair, ball screw, pinion and rack and imported servo motor to ensure the machine runs steadily with high precision.

◆ It adopts Italian HSD high-speed motorized spindle to ensure the machine runs steadily with lower noise and better cutting ability.

◆ It adopts vegetable oil microcrystalline cooling system to improve the tool life without poison and pollution.

◆ The rotary workbench can change the position among -90°、0° and +90° arbitrarily, one time clamping can finish milling for three sides.

◆ It adopts PA control system from Germany, intelligent CNC control system and straightforward human-computer interface make the operation much more convenient and efficient.

Technique Parameters

Technique parameters
X axis Stroke	3200mm
Y axis Stroke	300mm
Z axis Stroke	200mm
X axis Speed	0～140m/min
Y axis Speed	0～75m/min
Z axis Speed	0～75m/min
Spindle speed and Power	18000rpm/3kw
Work table position	-90°、0°、+90°
Cutter size	ER25-Ф8
Air Pressure	0.5～0.8MPa
Voltage	380V/50Hz
Power	6kw
Cutter cooling	Auto spraying and cooling
Processing dimension（W×H×L）	160×160×3200mm
Processing character	Can process three sides of profile per time loading profile
Dimension（L×W×H)	4525×1630×1900mm

Detailed Images

Certifications

Packing & Delivery

Company & Service

Parker Company Information

Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.

Parker service

What you can do if my machines have problems?
a.We can send you free components to you if your machines are in guarantee time.
b.We can send our engineers to repair your machines.
