SANY 50 ton price of mobile crane STC500S

FOB Price

USD $95,000 - $100,000 / Unit

1 Unit(Min.Order)

Supply Ability 80 Unit / Units per Month
Port SHANGHAI
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Get lowest price Inquiry Basket

You May Like

Product Details

Brand Name:	CHINA	Place of Origin:	Hunan, China	Certification:	ISO
Warranty:	1 Year	Application:	Construction
Condition:	New	Span:	6*7.2m	Rated Lifting Moment:	1774kN.m
Rated Loading Capacity:	30	Max. Lifting Height:	59m

Product Description

SANY 50 ton price of mobile crane STC500S

Please Contact

Aring Zhou

Wechat/Whatsapp/Mobile: +86 15855426352

Product Description

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Excellent and stable chassis performance /chassis system

Double-axle drive is used, providing good traffic ability and comfortableness under complex road condition with reliable traveling performance.

Engine has the multimode power output function, which reduces power consumption.

The use of tipping over early-warning technology provides high stability and safety of the overall operation.

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Highly efficient, stable, energy-saving and adjustable hydraulic system

Electrical proportion Hydraulic system load feedback, piston pump, electrical controlled valve and constant power control are applied to provide strong lifting capacity and good micro-mobility.

Unique steering buffer design is adopted to ensure stable braking operation.

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Ultra long, super strong and highly sensitive load lifting capacity

Five-section boom of high strength steel structure and optimized U-shaped cross reduces weight significantly with higher safety rates.

Jib mounting angles are 0°, 15°and 30° which ensures fast and convenient change-over between different operating conditions so as to improving working efficiency of the machine.

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Safe, stable, advanced and intelligent electric control system

Self-developed controller SYMC specially for engineering machinery is configured.

The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness and high reliability.

Timely feedback of data information can achieve the monitoring of the overall working status in real-time.

The load moment limiter equipped with the comprehensive intelligent protection system is used with accuracy within 3% to provide a comprehensive logic and interlock control, thus ensuring more safe and reliable operation.

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Excellent and stable chassis performance /chassis system

Double-axle drive is used, providing good traffic ability and comfortableness under complex road condition with reliable traveling performance.

Engine has the multimode power output function, which reduces power consumption.

The use of tipping over early-warning technology provides high stability and safety of the overall operation.

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Highly efficient, stable, energy-saving and adjustable hydraulic system

Electrical proportion Hydraulic system load feedback, piston pump, electrical controlled valve and constant power control are applied to provide strong lifting capacity and good micro-mobility.

Unique steering buffer design is adopted to ensure stable braking operation.

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Ultra long, super strong and highly sensitive load lifting capacity

Five-section boom of high strength steel structure and optimized U-shaped cross reduces weight significantly with higher safety rates.

Jib mounting angles are 0°, 15°and 30° which ensures fast and convenient change-over between different operating conditions so as to improving working efficiency of the machine.

SANY STC500S 50 Ton Truck Mounted Crane Mobile Crane Safe, stable, advanced and intelligent electric control system

Self-developed controller SYMC specially for engineering machinery is configured.

The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness and high reliability.

Timely feedback of data information can achieve the monitoring of the overall working status in real-time.

The load moment limiter equipped with the comprehensive intelligent protection system is used with accuracy within 3% to provide a comprehensive logic and interlock control, thus ensuring more safe and reliable operation.

Main Parameters

Capacity	Max. lifting capacity	50t
Dimensions	Overall length	13750mm
	Overall width	2750mm
	Overall height	3850mm
	Axles	4
	Axle distance-1,2	1450mm
	Axle distance-2,3	4400mm
	Axle distance-3,4	1350mm
Weight	Overall weight	42000kg
	Front axle load	16000kg
	Rear axle load	26000kg
Engine	Model	ns
	Rated power	250kw/2100rpm
	Rated torque	1425N·m/1200rpm
	Emission standard	Euro Ⅲ
Traveling	Max. traveling speed	85km/h
	Min.turning radius	12m
	Min.turning radius of boom head	14.5m
	Drive train	8 × 4
	Min. ground clearance	295mm
	Approach angle	18 °
	Departure angle	12 °
	Max. gradeability	40%
	Fuel consumption per 100km	≤ 45L
Main Performance	Temperature range	– 20 ℃~ + 45 ℃
	Min.lifting radius	3m
	Tail swing radius of superstructure	4m
	Boom section	5
	Boom shape	U-shaped
	Max. lifting moment-Base boom	1774kN·m
	Max. lifting moment-Full-extend boom	840.8kN·m
	Max. lifting moment-Full-extend boom+jib	318kN·m
	Length-Base boom	11.5m
	Length-Full-extend boom	43m
	Length-Full-extend boom+jib	59m
	Outrigger span(Longitudinal/Transversal)	6×7.2m
	Jib offset	0 ° 15 ° 30 °
Working Speed	Max. single rope lifting speed of main winch(no load)	130m/min
	Max. single rope lifting speed of auxiliary winch(no load)	130m/min
	Full extend/retract time of boom	100 / 120s
	Full raise/lower time of boom	80 / 80s
	Swing speed	0~2 r/min
Aircondition	HVAC in up cab	Cooling / Heating
Aircondition	HVAC in low cab	Cooling / Heating
