FN101B Portable Handheld Accurate Trace Oxygen Analyzer

Brief introduction

FN101B Portable Trace Oxygen Analyzer is a new-type intelligent industrial portable analyzer researched and developed by combining imported high-performance electrochemical sensor with new microcomputer technology based on the principles of electrochemical detection.

Application fields

Quick analysis on trace oxygen in protective gases for high-temperature sintering furnaces of nitrogen production by air separation, chemical process, magnetic materials, and so on; in protective gases for electronic industry; and in glass and building material industries, as well as various gas mixtures

Features

Imported fuel cell sensor adopted, featuring long service life, high accuracy, and quick response and immune to the interference of other gas components;

Automatic temperature compensation, eliminating the affect from ambient temperature;

128×64 lattice OLED display, able to simultaneously display parameters like oxygen content, date, and time;

Timed automatic storing function, and stored data available for viewing at any time;

Automatic range shifting; alarm point can be set at will within the whole range;

AC/DC power supply and flexible operation; built-in lithium-ion battery available for continuous operation of approximately 15 hours once fully charged; automatic alarm in case of low battery voltage;

Applicable for quick detection of trace oxygen in reducing gases, such as high-purity hydrogen;

Built-in air extracting pump and external filter can be added upon selection.

Technical parameters

1. Measurement range: 0.0~10/100/1000×10-6 O2;

2. Accuracy: ≤±5% F.S (0.0~10×10-6);

     ≤±2% F.S (10~100×10-6);

≤±2% F.S (100~1000×10-6);

3. Stability: Zero drift ≤ ±2% F.S/7d;

Span drift ≤ ±2% F.S/7d;

4. Repeatability: ≤ ±1%;

5.Sample gas flow: 400±10 ml/min;

6. Response time: T90 ≤ 10 sec.;

7. Resolution: 0.1×10-6;

8. Sample gas pressure: 0.05 MPa ≤ Inlet Pressure ≤ 0.25 MPa;

10. Operating environment: Temperature: -5℃~+45℃;

               Humidity: ≤ 90% RH;

10. Operating power supply: 1. 220 VAC±10%, 50 Hz±5%;

                        2. Rechargeable lithium-ion battery built in the instrument;

11. Overall dimensions: 256 mm (W) × 160 mm (H) × 330 mm (D);

12. Weight: About 4.5 kg
