EA100 Integrated Zirconia Oxygen Analyzer

TCZ-1Y integrated zirconia oxygen analyzer

Brief introduction

TCZ-1Y type is our company independently developed the first integrated type zirconia oxygen analyzer. The biggest advantage of this model is that the converter and detector are integrated into two parts, which saves the connection between the two.

The integrated zirconia oxygen analyzer in the probe structure and conversion circuit, selection of components, etc., have been greatly improved, in the structure of the use of explosion-proof instrument, its internal is also the basic requirements of explosion-proof instrument design. Due to the integration meter installed in the furnace body, surrounding environment temperature is higher, the tightness of the coupled with its own structure, so the main integrated circuit with military grade integrated circuit, the temperature limit of up to 120 DEG C, the lower limit of up to - 20 DEG C (temperature), in order to protect the instrument's reliability.

Technical indicators:

Range: 0-20.6%

Accuracy: 2%

Linearity: 1.5% of the full scale (basic error)

Repeatability: 1.5% of the full scale (basic error)

Response: respond to 90% < 5 s

Zirconium tube working temperature: 752 + 2 ℃

Measured gas temperature: 0-600 ℃ low temperature type

The 600-1200 ℃ high temperature type

The measured gas pressure: plus or minus 50 kpa

Ambient temperature: - 35 to 60 ℃

10% electricity source, AC 220 v, 50 hz

Power consumption: 200 w or less
