CM-01Desktop COD Water Quality Analyzer

CM-01Desktop COD water quality analyzer

Instrument features

The use of special quartz cuvette or cuvette colorimetric tube instead of in the same vessel ,

heating the reaction and colorimetric analysis

Reagent less , low running costs , low failure rate .

This instrument is suitable for a large batch of water samples in the laboratory

Reliable , fast operation , with temperature compensation function

High accuracy , good repeatability. Panel printer can automatically print out the measurement results .

232 data interface , upload the measurement results

Technical Specifications

Minimum detection limit             3mg / L
Range                            10mg / L ~ 2500mg / L
Relative error                      ± 5%
Repeatability                       ± 3%

Resistance to chloride interference    10000mg / L
A light source wavelength            610nm
The measurement method           Fast Airtight Catalytic law ( including photometry )

Optical stability absorbance drift      less than 0.002A in 20min
Output mode                       digital / printer
Power supply                       ~ 220V
Weight                             3.5Kg
Dimensions                         330mm × 320mm × 170mm
