GXH-3011G Flow Type NDIR Infrared Biogas Analyzer Methane Meter

Brief introduction

Used for online continuous analysis CO and CO2, a kind of gases such as CH4. Products are widely used in chemical, fertilizer, oil, metallurgical, steel, coal, power plant, cement, ceramics industrial process control; Air pollution and other environmental protection monitoring and emissions and public air quality monitoring; Agriculture, medical and scientific research.

Features

1.  standard 19 "case, all kinds of instruments cabinet match

2.  Optimize structure design, operation is stable and reliable

3.  Fast response, measurement data accuracy

4.  New digital headers to display

5.  Upper and lower limits can be set to alarm

6.  Simultaneous measurement of two components , but also increase the temperature , humidity measurement function

7. Signal output of the sync separator

Technical parameters

Measurement range: 0-100% (according to the needs of user can choose different in this range of specifications)

Minimum range: CO (0-50.0) x 10^-6; CO2 (0-100) x 10^-6; CH4 (0-300) x 10^-6

Zero drift: constant than plus or minus 1% / F.S / 7 d

Range drift: than constant plus or minus 1% / F.S / 7 d

Repeatability: more than 0.5%

Response time: more than 10 s
