Home > Products > Environment monitoring instruments > JZH-102 Wireless Indoor Air Quality CO2 VOC Detector Monitor
JZH-102 Wireless Indoor Air Quality CO2 VOC Detector Monitor
- SHENZHEN
- T/T Credit Card
You May Like
-
JRFW-2-22 Wireless Temperature and Humidity Sensor
-
IAQ CO2 Gas Detector With Temperature and Humidity
-
AT-2CO2 IAQ Indoor Air Quality Detector With Temperature and Humidity Wall Mounted Wifi Co2 Detector
-
EA012 Portable Multi-gas Detector
-
EA012 Portable Multiple Harmful Gases Detector CO2 Analyzer
-
ZR-3510A Air Pocket Air Sampler
Product Details
| Brand Name | YIMA | Place of Origin | Shaanxi, China | |
| Model Number | JZH-102 |
Product Description
Brief introduction
Collection, transmission integrated design, ultra-low power , intelligent management, intelligent transport . Transmission distance, the use of wireless 2.4G zigbee protocol , anti-interference ability. 16 physical channel selectable, 65535 Network ID can be set, networking ability. Suitable for indoor environmental measurement , agricultural greenhouses intelligent management.
Features
Large LCD screen displays the current information
Comply with 2.4GHz zigbee protocol
Ultra-low -power design , long product life
Measurement accuracy, anti-interference ability
The large number of network nodes , transmission distance
Technical parameters
Power supply | DC 12V (9V ~ 28V) or batteries ( lithium-ion battery 3.6V) |
Working frequency | 2.4GHz |
networks | ZigBee PRO protocol |
Communication distance | ≥800m ( open environment ) |
Channel | 16(0~0F) |
Network ID | 0x0000—0xFFFE |
Baud rate | 38400bps |
Range | Humidity: 0%RH~100%RH |
Accuracy | Humidity:±3%RH(5%RH~95%RH,25°C) |
Long-term stability | Humidity:<1%RH/y |
Data transfer format | Initiative to report |
Work Environment | -20°C~60°C;5%RH~95%RH(Non-condensing) |
Storage Conditions | -20°C~60°C;5%RH~95%RH(Non-condensing) |
Power consumption
| Maximum ≤160mA(Send the instant ) |
The response time | <15s(1m/s wind speed) |
Battery life | One year (1 times/min, 25 °C + / - 5 °C, power 19 ah) |
Outer shell | ABS white 53 mm x 180 mm x 130 mm (not including antenna part) |
Working time | ≤1s |
Start-up time | ≤1s |
Sleep time | Set the range of 60 ~ 65535 s (the default 60 s) |
Installation | Using the wall mounting |
Dear customer,
We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history .
Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science.
Through a long-time development,we own a national resources system of various professional talents , abundant supply for various components &parts and special materials, full producing &processing equipments , strong Technological standardization and a complete quality assurance system.
If you need OEM or ODM in manufacturing ,scientific research , market development and or you want to build your own brand in your country, it’s our honor to cooperate with you.In this way ,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba
We firmly believe that science and technology is no boundaries
Our mission is to make every effort to contribute to all humanity.
