Product Details
| Brand Name | YM | Place of Origin | Shaanxi, China | |
| Model Number | SV-2Q |
Product Description
Product Details
SV-2Q full-automatic exhaust gas analyzer, in accordance with non-light-disguising infrared absorption method, via micro-computer analysis, directly measure the thickness of HC, CO in the exhaust gas of vehicles .The analyzer introduces advanced foreign technology. It is composed of complete imported machinery cores, boasts the advantages of accuracy measurement, high endurance and speed. It’s utilized for auto-manufacturing factories, vehicle inspection stations and garages.
Technical parameters
1,Measurement range CO :0-10.0 10-2(%)
HC:0-10000 10-6(ppm)
2,Repeatability:≤±2%
3,Zero floating: CO: ±0.06 10-2(%)/1h
HC: ±30 10-6(ppm)/1h
4,Not exceed the allowed value for indication error(1 hour)
5,Indicated error: CO:±10%(relative error0-10%)
HC:±3(relative error0-2000ppm)
±5%(relative error2001-5000ppm)
±10%(relative error5001-10000ppm)
6,Environmental temperature temperature:0°C~40°C humidity ≤80% air pressure 60~105kPa power AC 220V±10%;50Hz 7,Preheat time 10min 8,Sampling method directly sampling 9. weight 14kg |
