LA - S1 Series Plant Image Analyzer

Brief introduction:

LA -s combination plant image analyzer system consists of: leaf area, disease spot area analysis, insect damage of leaf area, leaf color, crop canopy analysis, such as root analysis module, is a kind of convenient, can be used in the field or laboratory comprehensive analysis instrument, the precision is much higher than the traditional analyzer (or based on the type of the camera). The global uniform standard, can accurate, rapid, noninvasive determination of various parameters of plants, powerful functions, simple operation. The equipment is a combination of plants and crops in leaf area, leaf area, leaf disease spots, insect loss color (including chlorophyll content estimation), crop canopy, root system in six aspects of analysis function, widely used in agriculture, forestry, meteorology and other departments.

Technical features:

Plant roots can analysis measurements:

1) the total length of root;

2) root average diameter;

3) the total area of the root;

4) the root volume;

5) root count;

6) bifurcation count;

7) overlapping count;

8) root diameter class distribution parameters;

9) and nonuniform custom section diameter, can automatically measure the diameter of length, projection area, surface area, volume, etc., and its distribution parameters;

10) root long distribution;

11) to the root of color analysis, identify the root number of survival, the output of root diameter, length, different color projection area, surface area, volume;

12) to the root of topology analysis, automatically determine the Angle of the root of the number of connections, relationships, etc., can automatically analyze independently taproot or any a lateral root length and number of bifurcation, etc.;

13) can be shown separately the root of any diameter section of the corresponding parameters (step, gear diameter range of arbitrary change);

14) large quantities of automatic root analysis, analysis of the results figure editable correction;

15) can use the box dimension method, automatic root fractal dimension measurement. Of rhizobia can be accounted for in the root volume, in order to objectively determine the contribution amount of rhizobia body;

16) to the root of bifurcation tailoring, merger, connection, such as correction, correct operation can back, 100% to quickly get the right result. Accuracy: the root was plus or minus 1% or less; Area: excellent image quality < 1%, the standard image quality at 3% or less;

17) match special double lighting system, to provide high resolution color or black and white images, in addition to the shadow and the influence of uneven phenomenon, ensure the quality of image effectively;

18) using the statistical method to calculate the overlapping part of the root length, etc., can be stored or read TIFF, BMP, PNG, JPEG, PCX standard format of the image.

19) doubles as needles, area, volume measurement and cotton fiber thickness and length measurement.
