WF30 Colorimeter Color Testers Chromatic meter
- 30 Set / Sets per Month
- shenzhen
- T/T Credit Card
- WF-18 Colorimeter Color Testers Chromatic meter
- High accuracy price cost-effective Colorimeter WR-10
- LOM004 automatic hot inlaying machine
- LOM003 dip coating machine with variable speed 1-200mm
- LOM002 automatic precision grinding and polishing machine
- LOM001 fast cutting machine for crystal ceramics quartz glass rock and ore and metallographic samples
Product Details
Brand Name: | WF30 | Place of Origin: | Shaanxi, China | Model Number: | WF30 |
Power: | Electronic | Usage: | Auto Testing Machine |
Product Description
Techinical Parameters
Model | WF30 |
Display Mode | CIELAB,CIELCH |
Color Difference Formula | E*ab |
Illumination Condition | CIE Recommendation:8/d 45/0 Optional |
Light Source | LED blue excitation |
Sensor | Photodiode array |
Measurement Caliber | φ4mm/φ8mm/φ16mm Alternative |
Measurement Condition | Observer:CIE 10° Standard observer Light source: D50 D65 F11(TL84) Contain light way:SCI SCE |
Measurement Range | L: 0 to 100 |
Repeated Accuracy | E<0.05 (take the deviation average after 30 times measuring the whiteboard) |
Table Difference | E<0.2 |
Measurement Interval | 0.5 Sec. |
Storage Capacity | Type sample data : 100 with testing sample data: 200 |
Language Patterns | English/Simplified Chinese |
Battery Charging Time | 8 hrs |
Battery | Li-ion battery, 5000 times Measurement |
Lifetime of Bulb | 5 years more than 1.6 million measurements |
Display Screen | TFT true color 2.8inch@(16:9) Resolution ratio:400x240 |
Interface of External | USB2.0 (USB-B)- data communication with color analysis system software RS-232 (115200bps)- connected with micro printer |
Working Temperature Range | 0℃-40℃(32℉-104℉) |
Storage Temperature Range | -20℃-50℃(-4℉-122℉) |
Humidity Range | Relative humidity less than 85%,without condensation |
Weight | 700g |
Size | 199*68*90mm |
Size of Exterior Package | 400*240*340mm |
Standard Accessories | 3000mAH Li-ion battery/AC adapter/USB Data line/CD Color analysis software /User manual/Warranty card |
Optional Accessories | Flour measuring device/Liquid measuring device/Micro printer |
