SPE-10 Automatic Solid Phase Extraction Apparatus

SPE-10 Automatic Solid Phase Extraction apparatus

Introduction

SPE-10 workstation is perfect complement of fast and high-through SPE.SPE-10 workstation can process 6 samples each time. SPE-10 is modular design,Allows users handle a large number of samples by adding separate workstation. Each workstation compatible with a variety of solid phase extraction tubes,and 6 channels are independent without cross-contamination and 2 components can be collected automatically. SPE-10 can handle various types of samples. Applications including drug testing organizations, CRO companies, forensic testing, clinical laboratories, pharmaceutical / biotech companies, pharmaceuticals, food and beverage companies.

Feature

1 Positive pressure Technology

Ensure a stable flow rate, high accuracy and repeatability,we use High-precision syringe pump and stable and accurate sample delivery according to a specified sample.Do not worry sample block thepump because of the specific design of sample without pump. When the solid phase extraction column was severely blocked cause the pump pressure is too high,protection will stop the pump automatically.

2 Fully automatic operation

You only need to set the experimental conditions.Activation of solid phase extraction column and elution, sample loading, elution and other operations completeautomatically.Compared with other traditional techniques, SPE-10 reduces 90% the cost of solvent and human.

3 Independent design of channels

6 channels of each SPE-10 workstation is independent completely, avoiding the possibility of cross-contamination and improving the accuracy of the experiment.

4 Multi-station modular design

SPE-10 operating software can achieve the parallel control of 32 workstations. Station is independent, improve efficiency greatly.

Instrument features

5 Continuous treatment of six samples of each batch, 1mL, 3mL, 6mL and 10mL tubes can be used.

6 channels of each SPE-10 workstation is independent completely, avoiding the possibility of cross-contamination.

7 Five solvent can be choosed, column preconditioning, sample added, washing impurities, target elution all done automatically.

8 Performance multi-function pump, precise controlling flow rate and flow volume.Flow rate range: 1~20 mL/min.

9 Sample volume range: 0-100 mL.2 component collection can be achieved.Collection bottle rack has different specifications.

10 Independent workstation parallel control can be achieved(32).Sample processing can be improved(192 / time.

11 Stations are independent, you can set different test methods.

12 Including computer and keyboard control,Simple operating software SPE

13 Overpressure alarm,Channel indicator and Status indicator

14 Compact equipment, saving laboratory space, the experiment can be placed in fume hood

15 Reduce operator exposure to the chemical aerosol

Technical parameters

Typical applications:

melamine sample preparation of milk powder

Recovery rate
