GC-9560-EG Helium Ionization Gas Chromatograph

Introduction:

GC-9560-EG helium ionization gas chromatograph for electric gase is suitable for the detection of trace impurities in the gases used in electronic industry, such as high purity ammonia, carbon tetrafluoride, sulfur hexafluoride, nitrogen trifluoride, silane and etc. This instrument is equipped with high sensitive pulsed discharge helium ionization detector(PDHID), adopting the patented heart-cutting and back-flushing technology owned by Huaai Chromatography, configured with injection switching valve with purging protective gas circuit and imported helium purifier, able to complete by one time the detection of common impurities or other special impurities such as H2,O2(Ar),N2, CH4, CO, CO2 and etc.

Technical parameters:

Detection limit (ppb)

 Temperature control indicators:

Column oven: room temperature, 8 ℃~400 ℃ Accuracy±0.1 ℃

Sampler: room temperature, 8 ℃~400 ℃ Accuracy±0.1 ℃

Detector: room temperature, 8 ℃~400 ℃ Accuracy±0.1 ℃

The number of temperature control: 8 channels

Temperature programming: 8 orders

Cooling speed: within 7 minutes (350 ℃ to 50 ℃)

Helium ionization detector (PDD):

 Discharge mode: pulse discharge

Baseline noise: ≤0.1mv

 Baseline drift: ≤0.5mv/30min

 Detection limit: ≤1.0×10-10g/ml

Carrier gas purifier:

Gas able to be purified: He, Ar, Ne, Kr, Xe and Rn

 Maximum operating pressure: 1000 Psi

 Gas removing: H2,O2,N2,CO,CO2,CH4,H2O,NO,NH3,CF4 and etc.

 Residual concentration: ≤10ppb

Performance of workstation:

 Communication interface, RS232 / USB interface

High accuracy: 24-bit high accuracy A/D

Resolution: ±1uv

Input level range:-5 mv to + 1 v

 Sampling frequency: 20 times per second at maximum

 Dynamic range: 106

Integral sensitivity: 1μv·sec

 Linearity: <±0.1%.

Reproducibility: 0.06%.

Other parameters: size, weight and power supply

 Size: (W)655 mm x (H)500 mm x (D)480 mm deep

Weight: ~ 48 kg

Power supply: 220V±22V,50Hz,Power ≥2kW
