PP cartridge stainless steel water filter housing
- 100 Set / Sets per Month
- Shanghai
- T/T Credit Card
You May Like
-
Industry water treatment pp ss stainless steel cartridge filter housing
-
Waste bag multi high pressure water filter housing
-
Manufacturer pvc single bag filter housing for industrial wastewater
-
Stainless steel cartridge water filter housing for chemical industry
-
High flow rate plastic bag pp filter housing for power plants
-
Stainless steel water plastic bag filter housing for chemical industry
Product Details
| Brand Name | QILEE | Place of Origin | Shanghai, China | |
| Model Number | QH01P1S |
Product Description
PP cartridge stainless steel water filter housing
Vertical High Security Filter
Large flow filter shell through professional design,can be achieved in a compact space greater flow.
Can be perfectly matched to install 3M,PALL,Parker,Graver,Horizon...And other domestic brand of filter cartridge.
Automatic welding seam welding technology,weld strong and beautiful.
The open cover structure adopts quick flange,which is easy maintenance and quick to replace the filter element.
The equipment has high strength and taper stainless steel central rod,that can be conveniently and accurately installed,and the filter element is prevented from deforming.
Stainless steel water filter housing Technical Parameters
Filter material:SS304,316L,carbon steel
Filter cartridge size:diameter 6"(152mm);
height:40"or60"(1016mm)
Seal type:O Type Ring
Surface treatment:Matt
Filter accuracy:1,3,5,10,20,30,50,70,100um
Stainless steel water filter housing selection data sheet
Model | Filter cartridge qty | Filter cartridge height | D | A | B | C | E | F | L | N1/N2 | N5/N6 | N3/N4 | Design flow |
QLB01-40P | 1 | 40" | Ø200 | 1200 | 300 | 200 | 400 | 210 | 1700 | DN80 | G3/4" | G1/4" | 40 |
QLB02-40P | 2 | 40" | Ø350 | 1200 | 300 | 275 | 550 | 370 | 1800 | DN100 | G3/4" | G1/4" | 80 |
QLB03-40P | 3 | 40" | Ø400 | 1200 | 400 | 325 | 650 | 420 | 1950 | DN125 | G3/4" | G1/4" | 120 |
QLB04-40P | 4 | 40" | Ø450 | 1200 | 450 | 350 | 700 | 470 | 2020 | DN150 | G3/4" | G1/4" | 160 |
QLB05-40P | 5 | 40" | Ø500 | 1200 | 450 | 375 | 750 | 520 | 2070 | DN200 | G3/4" | G1/4" | 200 |
QLB06-40P | 6 | 40" | Ø550 | 1200 | 500 | 400 | 800 | 570 | 2130 | DN200 | G3/4" | G1/4" | 240 |
QLB07-40P | 7 | 40" | Ø600 | 1200 | 500 | 425 | 850 | 620 | 2170 | DN250 | G3/4" | G1/4" | 280 |
QLB08-40P | 8 | 40" | Ø650 | 1200 | 550 | 450 | 900 | 670 | 2260 | DN300 | G3/4" | G1/4" | 320 |
QLB10-40P | 10 | 40" | Ø700 | 1200 | 600 | 475 | 950 | 720 | 2350 | DN350 | G3/4" | G1/4" | 400 |
QLB12-40P | 12 | 40" | Ø750 | 1200 | 600 | 500 | 1000 | 770 | 2370 | DN350 | G3/4" | G1/4" | 480 |
QLB14-40P | 14 | 40" | Ø800 | 1200 | 650 | 525 | 1050 | 820 | 2460 | DN400 | G3/4" | G1/4" | 560 |
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
