Multifunctional Automatic Floating & Sinking Fish Meal Processing Line

The Drier is composed of a horizontal crust, a revolving shaft, weld with a heating plate that has vanes. The plates can heat the fish meal, at the same time push fish meal towards the outlet by the vanes. Steam is evenly distributed into the heating plate by the allotter. Since the steam and condensate flow respectively in channels on the plates, so as to stabilize the high temperature.

With the rotation of shaft, fish meal is agitated by the vanes and heating plates, thus to keep the best contacted with the shaft and plates. Vapors from heating is let out from the top by the pipeline, with the weak vacuum inside pipeline, less cold air is absorbed and no steam leaks. The Steam enters through inlet, and condensate drained out from outlet.

Features Of Fish meal production line

1. Fitting with Clutch, the Drier could be directly restarted with loading when sudden-stop during operation, avoid emptying inside materials.
2. With steam jacket, increase drying area, properly improve drying efficient, to assure material drying adequately.
3. Compression handles, compact structure, convenient open & shut.
4. The Main shaft is made of super thick quality seamless pipe.
5. By means of drainage system, take condensate back to boiler, therefore improve boiler efficiency, meanwhile reduce energy consumption.
6. With steel foundation, no concrete foundation, changeable installation position.

Boiler machine parameter of Fish meal production line

Extractor machine parameter of Fish meal production line

 Dryer machine parameter of Fish meal production line

 Fish meal production line picture

About packaging, for small size or single machine, we can offer free fumigation wooden case with steel frame, it not only can protect machine from damage, but also avoid checking when exporting.

For multiple machines or production line, it's better to loaded in standard container 20GP, 40GP, 40HQ, usually it needs wrapped with plastic firstly, then loaded in container.

we can offer EXW, FOB and CIF terms.

EXW: You arrange the shipping details from our factory to your port by yourself.

FOB: We arrange freight transport to Qingdao, Shanghai or other ports of China, then you arrange the shipping details from China port to your country port.

CIF: We arrange all shipping details to your country port, and ensure machines smooth arrival.

Kaifeng Rainbow Machinery Co., Ltd. is a domestic large-scale new energy environmental protection equipment manufacturers in China. The registered trademark is "Rainbow".

Our company has combined Research and Development, Production, Sales and Service in one, and our main product have Wood Crushing and Recycling Workstation, New Energy Particle Machinery, Feed Machinery, Organic Fertilizer Machinery, Broken machinery. Totally, have a lots of products, more than 300models, which make our company the most professional development and production of high-tech enterprises of new energy environmental protection machinery manufacturer in China.

1. Help you choose the most suitable machine.

2. Making the machine according to your request.

3. Give you machine’s details and video for help you use the machine more better.

4. One year warranty

5. Quality problem,we will send you the accessories.

6. Free repair whole using life without extra charge.

1. What's the delivery time?
We will deliver the product in 7 days after receiving the deposit.
2. What's your payment terms?
We can accept various payment terms if it is convenient for you.
3. what's your MAQ?
Our MAQ is 1 piece.
4. What's the lifetime of the wearing parts?
The material of our product is of high quality, and the lifetime of our wearing parts is twice longer than the others,including the roller skin, die and bearing.
5. What is your warranty?
12 months except the spare parts.
6. Will you send engineers to install the plant?
Of course yes,but at an extra cost will be paid by customers. Or you can get local contractors to do the commissioning and we send one supervising engineer.

7. Do you have some foreign customers using your equipments?
 Yes , we have customers all over the world.
