Factory Directly Supply Lowest Price Cotton Seed Peel Machine Cotton Seeds Dehuller Machine

 1.Introduction of cotton seed peel machine

Best sale high efficiency cottonseed sheller/disk cotton seed husking machine to take the out seed shell that for the cotton seeds oil plant process.

Disk cotton seed peel machine is suitable for delinted cotton seeds , peanut and other oil material shelling process , also can be used as the crusher equipment for soybean , peanut during the oil press process . The gap between the fixed disk and the move disk is adjustable to suit for different process working . and to avoid the damage of raw material at the same time .

2.Structure and function of cotton seed peel machine

Disc type sheller is also called the tooth plate sheller.This cotton seed peel machine is mainly used for cotton seed shell. Other oil crops such as peanuts, tung seed can also be used.

Disc type sheller is mainly composed of feeding mechanism, shell, drive mechanism and adjusting mechanism parts:

1, feeding mechanism, including the role of adjusting plate feeding impeller feeding mechanism is to make the material evenly, continuously into the shell body.Feeding the impeller is installed on the feed shaft.Feeding shaft there are generally two root, above is equipped with a pair or two pairs of feeding the impeller.Feeding shaft driven by gear, to drive the feeding impeller stirring animals.Feeding impeller with adjustment plate below, it can open and close, to control the size of the feed rate.Adjustment plate available manual adjustment, also can use the control gear rack mechanism.

2, shell institutions including living mill dying mill and knife.The function of it is broken and stripping material shell.Die mill installed on the fixed plate, a fixed plate and the fuselage together, die fixed plate with bolts and connecting to the mill table.Live mill installed on the rotating disk, and the driving mechanism drives the rotary.Each mill by 4 to 6 piece of fan mill piece Mosaic circular ring, and the countersunk head bolt.Rotating plate is equipped with four play knife, its role is to put into the mill between the clearance of the material into a millstone.

3, the role of the driving mechanism is driven feed and rotation disk drive shaft rotation.Motor is directly driven pulley rotation plate, at the same time, through the pulley, gear drive feeding shaft rotation.When clearance adjustment a millstone, pulley can produce axial movement, but not for displacement, it does not affect transmission.

3.Parameter of cotton seed peel machine

About packaging, for small size or single machine, we can offer free fumigation wooden case with steel frame, it not only can protect machine from damage, but also avoid checking when exporting.

we can offer EXW, FOB and CIF terms.

EXW: You arrange the shipping details from our factory to your port by yourself.

FOB: We arrange freight transport to Qingdao, Shanghai or other ports of China, then you arrange the shipping details from China port to your country port.

CIF: We arrange all shipping details to your country port, and ensure machines smooth arrival.

For multiple machines or production line, it's better to loaded in standard container 20GP, 40GP, 40HQ, unually it needs wrapped with plasitc firstly, then loaded in container.

 1. Help you choose the most suitable machine.

2. Making the machine according to your request.
3. Give you machine’s details and video for help you use the machine more better.
4. One year warranty
5. Quality problem,we will send you the accessories.
6. Free repair whole using life without extra charge.

 Kaifeng Rainbow Machinery Co., Ltd is specialized in production of machines used in food, feed, farm and tech field. We have our own professional research and development department, and specialized production base. Our machinery include food processing machine, pellet mill and supporting machine, Oil Mill Equipment or Oil Presser, wood working machinery and so on.

 *How do you guarantee I can receive the goods that ordered after make the payment?

Please rest assured that you will receive the goods in time, we are a legally established company supervised by the government, and is registered in customs of China and China Chamber of International Commerce. Besides, we are the golden member of Alibaba and has been checked by the third party as the real and legal company, what is more important, honesty and trustworthiness is our basic principle and our company life.

 * How to make the payment?

Normally, when the order value is below USD10,000, we accept the payment by T/T or Western Union or Cash, L/C will be accepted when the order value is over USD10,000. For T/T, the customer can choose 100% in advance or 30% in advance, and pay the 70% balance before shipment.

 *Date of delivery?

We will arrange the production and shipment as soon as possible when we received the deposit, and update the information with the customer on line.

 *Suitablity of motor?

As there are many volatage standards in different countries in the world, so the original motor equipped on the machine would not suitable to be used with the customer's local power supply, when this situation happend, please send us your exact information of the power supply available, then we can modify the motor accordingly.

 *After sale service?

For most of the machines, the quality is guaranteed for one year since the date of shipment expet wearing parts, we supply the on-line service for all the machines, and also supply the spare parts all the time with cost price, for some complicated machine or plant, we can send our engineer overseas too.
