Application:
This machine is mainly used for syrup, juice, wine, drinks, soybean sauce, vinegar, cod-liver oil, olive oil, essential oil, hair oil, ink, disinfectant, injection, and so on various liquid automatic filling and production, has function of bottle unscrambling, washing, filling & capping, and labeling.
Proformance and features
Adopts plunger type metering pump filling, high precision; The structure of pump adopts fast
disassembly institutions, easy to clean and disinfect.
PLC control system, color touch screen display, machine has function of counting automatically.
The filling nozzle was equipped with drip-proof device.
When filling liquid, the filling nozzle dive into the bottom of bottle, rising slowly, it can effectively prevent bubbles.
Main electrical elements adopts foreign well-known brand
Machine body is made of 304 stainless steel, full compliance with GMP standard.
1.The parts which contact liquid are SUS316L stainless steel and others are SUS304 stainless steel
2.Including feeder turntable,effective cost/space saving
3.It has intuitive and convenient operation, measuring accurate, positioning precision
4.Fully in accordance with the GMP standard production and passed CE certification
5.Siemens Touch screen/PLC+UK brand peristaltic pump+Servo motor control
6.No bottle no filling/plugging/capping
Main Technical Specifications:
Filling Volume |
2-30ml |
Productivity |
30-60bottles/min 70-100bottles/min |
Filling Precision |
≤±1% |
Power Supply |
380V/50Hz |
Capping Rate |
≥99% |
Stoppering rate |
≥99% |
Air Supply |
1.3 m3/h 0.4-0.8Mpa |
Power |
2.0 kw |
Weight |
550 kg |
Dimension |
1800*1000*1500mm
|
