Used Adhesive Tape Coating Machine
Used Adhesive Tape Coating Machine
Application filed
This type coating machine, specializing in making release paper, protective film, PE/PET tape, masking tape, double side tape, cloth tape and so on
Machine information
Raw materials of the machine adapt to |
OPP, PET, PVC, PA, CPP film, Aluminum foil and other types of plastic film and paper, etc. |
||
Width of material |
800mm, 1000mm, 1100mm, 1300mm, 1600mm, 1800mm |
||
Max. mechanical speed |
150-180m/min |
||
Max. Speed of laminating |
120-160m/min (According to the material) |
||
Dry oven length |
12.5-18m, can be customized. |
||
Operation or control system |
Potentiometer |
Operation panel |
PLC |
Mode of unwinding and rewinding |
Single shaft, Or double-station rotary rollers for unwinding |
||
Diameter of unwinding and rewinding |
600mm-1500mm |
||
Unwinding brake |
Magnetic powder brake or air brake |
||
Tension controller |
Automatic constant tension control for unwinding, torque motor or variable frequency motor for rewinding |
||
Edge position system |
E.P.C or L.P.C automatic edge system, control accuracy≤1mm |
||
Coating modes |
Cobwebbing rollers coating, Three-roller, steel wire, comma coating, or anti-comma coating |
||
Oven |
Side-opening or bottom opening door type |
Arc top-opening door type (controlled by pneumatic system) |
Arc top-opening door type (controlled by pneumatic system) |
Temperature control system |
PID intelligent temperature controller, temperature control accuracy≤±2°C |
||
Electric heating controller |
AC contactor |
Solid-state contractor |
Silicon-controlled rectifier |
Reflector cover |
Stainless steel |
||
Stainless steel corridor |
Optional |
||
Rewinding controller |
Torque motor |
Variable frequency motor |
|
Over-heating protection |
All the motors of the fans are equipped with over-heating protecting system |
||
Alarm of density of combustible gas |
Without |
Optional |
Equipped |
Other protecting system |
Tension hold when machine stops, Static elimination |
||
