Tabletop Small CNC Metal Milling Machine Price VMC460L

Name: Tabletop Small CNC Metal Milling Machine Price VMC460L
Availability: InStock

FOB Price

US$ 21500.00 - 22000.00 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Main feature

Technical parameter

Item	unit	VMC460
Table size	mm	800*300
Load capacity	kg	200
T slot		3-14*80
X axis travel	mm	460
Y axis travel	mm	320
Z axis travel	mm	460
Distance from spindle center to table	mm	90-550
Distance from spindle center to columnslide way	mm	395
Tool shank		BT30/BT40
Spindle speed	RPM	10000
Spindle motor power	KW	3.7
MAX.diameter of tool	mm	80/120
MAX,length of tool	mm	200
MAX.weight of tool	kg	6
X/Y-axis rapid moving speed	mm	20000
Z axis rapid moving speed	mm	20000
Feed rate	mm/min	1-4000
Positioning accuracy	mm	0.012
Repeated positioning accuracy	mm	0.007
Out dimension	mm	180017502000
Weight	kg	1900

Main components

NO	ITEM	Model Number	Place of origin	Quentity	Remarks
1	Spindle	BT40(socketφ120)	Taiwan	1set
2	Boosting unclamping cylinder	3.5T	Xieqing (Wuxi)	1set
3	Bamboo hat type knife managine	BT40-16T	Taiwan	1set	Standard
4	Disc cutter	BT40-16T or 20T	Taiwan	1set	Optional
5	X ball screw	3210/P3	Domestic	1 pair	Taiwan Optional
6	Y ball screw	3210 /P3	Domestic	1 pair	Taiwan Optional
7	Z ball screw	3210/P3	Domestic	1 pair	Taiwan Optional
8	Special bearing		NSK or FAG	6 pairs
9	Double disc coupling		Domestic	3
10	Cooling pump		Taiwan	1
11	Lubrication system	Single track damping type	Nanjing	1 set
12	Pneumatic system	AirTAC	SMC	1 set
