XK7125 dental zirconia milling machine for dental zirconic blocks
Specifications
Item |
Unit |
XH7125 |
|
Table travel(X,Y,Z) |
mm |
400×250×400 |
Table size |
mm |
600×250 |
Number/Width/Distance of T-slot |
mm |
3-14-75 |
Distance from spindle nose to table surface |
mm |
60~460 |
Distance from spindle axis to column guideway |
mm |
325 |
Taper of spindle |
|
BT30 |
Spindle speed range |
r/min |
60~6000 |
Spindle motor power |
kw |
3.7 (AC servo)3.7 |
Rapid traverse speed(X,Y,Z) |
m/min |
6 |
Cutting feed speed(X,Y,Z) |
mm/min |
2.5~3000 |
Max.dimension of tool |
mm |
φ92 |
Max.weight of tool |
kg |
5 |
Positioning accuracy |
mm |
±0.015 |
Repeat positioning accuracy |
mm |
±0.075 |
L×W×H |
mm |
1650×1600×2000 |
Net weight |
kg |
1530 |
Main configuration
Standard:
1,CNC system: SIEMENS 808D.
2,Spindle: Taiwan high speed(6000rpm),precision spindle unit.
3,Ball screw: Taiwan's precision ball screw.
5,protection: full outer stainless steel inner defense and protection.
Optional:
KND-1000Ⅱ,Siemens 828D.
CNC fourth axis.
Automatic chip removal system.
