VIK-5C Five-axis CNC Tool Grinding Machine Specification Five-axis CNC Tool Grinding Machine

 VIK-5C five-axis CNC tool grinding machine specification five-axis CNC tool grinding machine

1. Main features

(1) The machine tool realizes five-axis CNC grinding, and adopts special cnc system and special tool software,With 2D and 3D demonstration functions, complete display of tooling shape,Avoid error of parameter setting and damage to workpiece and machine tool, avoid interference collision of machine tool.

(2)Multi-function, high quality, high performance,

(3)High precision: positioning accuracy 0.006mm (whole process), repeat positioning accuracy 0.004mm,

(4) The machine has a workpiece probe system, it can automatically measure the parameters such as the outer diameter helix angle, when the tool manufacturing and grinding;

(5)Adopt import brand servo motor, linear guide, ball screw, bearing, etc.

(6)The machine can store hundreds of tool parameter models, to facilitate the user a variety of types of production. Do not need to adjust the machine settings, only need to use the corresponding tool model for production, so easy and fast.

(7) The machine setup is simple, no high standards for the operators, only need to enter the parameters according to the tool.

2.Technical Parameters

3. Standard configuration

(1) CNC system:Taiwan SYNTEC.

(2)Basic grinding software package (milling tool, drill , shape tool).

(3)The workpiece probe system, imported Italian.

(4)X, Y, Z direct axis C3 thread, H class linear slide rail, straight connect drive.

(5)X, Y, Z, A, C, Five-axis drive using servo motor.

(6)Automatic lubricating system.

(7)Five-axis handheld pulse generator

(8)Leakage protection function

(9)The grinding wheel clamping connection component.

(10)Pneumatic spring clamping head 4,6,8

(11)Spindle oil cooler

(12) Machine-specific toolbox.

 4.Main purpose

This product is a tool making and grinding special machine tool. It can produce all kinds of flat head milling tool, round nose milling tool, ball head milling tool, drill, reamer, forming profile tool, part of the non-standard rotary tool, Can also be grinding and remanufacturing on some of the tools, restore the accuracy and use function of wear tools

We can configure a special tool grinding software package according to the special requirements of customers, Its function is powerful.

VIK-5C five-axis CNC tool grinding machine specification five-axis CNC tool grinding machine with standard export package.

GUARANTEE AND AFTER-SALE SERVICES:

1.one year guarantee for whole machine

2.24-hours technical support by E-mail or telephone

3.User-friendly English software or Russian or Spanish, Users manuals and Detailed Videos/CD

4.Provide extra accessories for the machine

5.Also provide service of make program according to your drawings

6.Customized or special design is OK.

Taian Haishu Machinery co.,Ltd. is specialized in design production and sales of CNC machine tools. The leading product is "HAISHU" brand CNC lathe,CNC Turning center, Machining center, etc..

Our company is equipped with the ministry of domestic trade and foreign trade, with independent import and export right. Product best-selling more than 20 domestic provinces and municipalities and autonomous regions, and exported to the US, Britain, Germany, Italy, Turkey, Greece, Sweden, Bulgaria, Romania, Denmark, Lebanon, Czechoslovakia, New Zealand, Australia, Peru, Ecuador, Colombia, Chile, Argentina, Russia, Belarus, Lithuania, Serbia, Tunisia, Bahrain, South Africa, South Korea, India, Indonesia, Malaysia, Thailand, the Philippines, Egypt, Iran, Bangladesh, Iraq, Yemen, Mongolia,etc. more than 45 countries.

We have years of CNC machine tool development and manufacturing experience, in order to "science and technology innovation, good faith service" business philosophy in close cooperation with old and new customers, grow together, common development.
