CNC450T Twin Spindle Double Live Tooling Turret Cnc Turning Milling Machine

No.

Item

Unit

Technical parameters

CNC150T

CNC250T

CNC350T

CNC450T

CNC550T

1

Maximum turning diameter on lathe’ body

mm

150

250

350

450

550

2

Maximum workpiece length

mm

350/450/550

650/750/1000

3

Maximum turning diameter

mm

150

250

350

450

550

4

Spindle nose type and code

mm

A6

A6

A8

A8

A12

5

Hydraulic chuck

mm

2-φ100

(4")

2-φ160

(6")

2-φ200

(8")

2-φ250

(10")

2-φ300

(12")

6

Front spindle bore taper

1:20

7

Spindle bore

mm

38

40

60

60

70

8

Maximum load-bearing chucked components

kg

50

100

500

500

800

9

2 - servo spindle motor speed

mm/min

0-8000

10

Rapid traverse X / Z

mm/min

40000

11

CS1; CS2 main servo motor power

kW

3.7

5.5

7.5

7.5

11

12

X1; X2 servo motor maximum torque

N.m

6

10

10

10

15

13

Z1; Z2; Y servo motor maximum torque

N.m

10

15

15

15

20

14

Power Specifications

v

380±10%. 50Hz±1Hz

15

Carrier transfer time (one station)

s

1.6(Horizontal12)

16

Carrier transfer repeat positioning accuracy

0.005"

17

X1-axis travel

mm

100

150

200

300

300

18

Z1-axis travel

mm

350/450/550

650/750/1000

19

B-axis(sub-spindle) travel

mm

650/750/850

950/1050/1300

20

X2-axis travel

mm

100

150

200

300

300

21

Z2-axis travel

mm

350/450/550

650/750/1000

22

Y1;Y2-axis travel

mm

50

100

150

200

250

23

Biaxial dynamic docking concentricity

mm

0.004

0.004

0.005

0.005

0.005

24

Hydraulic servo turret form

Horizontal 12-station power turret

25

Knife handle size

mm

20*20

25*25

25*25

32*32

32*32

26

Net weight

kg

3000/3500/4000

5500/6500/8500

27

Size(L×W×H)

mm

2000/2100/2200*1350*1750

2600/2700/3000*1600*1950
