Slant bed cnc lathe machine TCK6350
Standard configurations
FANUC controller
8 tool post
Hydraulic chuck
Linear guide rail from Taiwan
Self lubrication, lighting system, coolant system.
Usage
TCK6350 is applicable to automobile, motorcycle, electronics, aerospace, military,
oil and other industry. It could turn the conical surface, circular arc surface, end face of the rotary parts, could also turn various metric and inch threads etc, with higher efficiency and higher precision in bulk.
Items | TCK6350 |
Max.swing over bed | Ø 520mm |
Max.swing over cross slide | Ø 220mm |
Max. processing length | 410mm |
X/Z axis travel | 500/500mm |
Spindle unit | Ø200mm |
Spindle nose | A2-6/A2-8 |
Thu-hole dia.of spindle | Ø66mm |
Spindle drawn tube diameter | Ø55mm |
Max.spindle speed | 3000rpm |
Chuck size | 10’’ |
Spindle motor | 7.5/11KW |
X/Z axis Position accuracy | 0.02/0.02mm |
X/Z axis repeatability | 0.006/0.006mm |
X/Z axis feed motor torque | 7.5/7.5N.m |
X/Z axis feed motor power | 1.88KW |
X/Z axis fast feeding speed | 18/18mm/min |
Tool post type | optional |
Cutting tool shape size | 25*25 |
Guide form | 45 degrees slant rail |
Total power capality | 14/18KVA |
Machine/dimension | 2550*1440*1710 |
N.W. | 2900KG |
A: You can choose FOB,CIF, DDU or other terms. You can book ship or I can book ship for you.
A: You can make the inquiry online on Alibaba, or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 2 hours on work days, and within 24 hours on holiday.
A: You can choose machine on our website accodring to your request. Or You can let our seller know what is your request specifcation or what is your parts, so let our seller recommend suitable machine to you. We have do trade machine years, and export machine to over 100 countries. We have CE, ISO, SGS and other quality certificate.
A: We can make the deal on Alibaba online platform, you can pay by T/T or Credit card. You can also pay to my company business bank account. You can also choose L/C or other way.
A: If the machine you will order is standard machine, we can ready the machine within 15days. If special machine, please confirm with our seller. The ship time is about 30 days to Europe, America. If you are from Australia, or Asia, it will be shorter. You can place order according to delivery time and ship time.
A: warranty is one year, but we will offer lifetime service for machine.
