Cheap Hoizontal Metal Cnc CK6150A Machine Lathe With SIENENS FAUNC

FOB Price

US$ 10,000 - 15,000 / Set

1 Set(Min. Order)

Port Shanghai Qingdao Ningbo
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HICNCE	Place of Origin	Shandong, China
Model Number	CK6150A
Condition	New

Product Description

Configuration and specification

1.System: GSK,
2.Manual 3-jaw chuck, 4-station electric tool post.
3.Manual tailstock, Semi-Rugged or full protect doors
4.Coolant system;Lighten system; Automatic lubrication system

Item	CK6150A
Max. swing dia. over bed	Φ500mm
Max. swing dia. over cross slide	Φ280mm
Processing length	750mm/1000mm/1500mm/2000mm
Width of the bed	400mm
Dia. of spindle	Φ82mm
Spindle taper	1:20/Φ90
spindle nose	Type of spindle head D-8
Spindle speed	150-2500rpm
Spindle speed step	step-less
chuck size	250mm
Tool holder	4 station
Tool bar section	25X25mm
Main motor power	7.5KW
X/Z axis position accuracy	0.02/0.025mm
X/Z axis repeatability	0.01/0.012mm
X/Z axis torque	6/10N.M
X/Z axis travel	360/750mm/1000mm/1500mm/2000mm
X/Z axis fast feeding speed	8/10 M/MIN
Tailstock sleeve travel	150mm
Tailstock taper	MT5
Dimension	2410/2660/316015601730mm
weight	2800/3200/3500kg

Main fectures

1. The base of the machine is made of cast iron which is heavy enough and of good rigidity and stability.
2. independent spindle, stepless speed regulation, with lower noise and high- standard machining accuracy, is an environmental- protective machine.
3. The spindle is the high- rotate speed and sophisticated bearing, with smooth surface. The extra size diameter of the spindle bore isφ82mm while the diameter of chuck is φ250mm.

Brands of standard configuration of CNC	GSK980TB2
Structure style of spindle	Independent spindle, stepless frequency control
Position of CNC system	on the right side, right-left move
lighting system	standard T8 fluorescent lamp
Cooling system	water cooling
Lubrication system	automatic lubrication controlled by microcomputer
Brands of motor-driven tool carrier	Hongda and Sanhe
Type of cabinet base	Whole cast iron

CNC Lathe CK6140A

100% Response Rate

Swiss type cnc lathe H-F203E
