VMC600L CNC Milling Machine Vertical Machining Center Price

Name: VMC600L CNC Milling Machine Vertical Machining Center Price
Brand: HANKUI
Availability: InStock

FOB Price

US$ 18,900 - 37,900 / Set

1 Set(Min. Order)

Port Qingdao Port for VMC600L CNC Milling Machine Vertical Machining Center Price
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HANKUI	Place of Origin	Shandong, China
Model Number	VMC600L	Type	Vertical
Certification	ISO9001 CE	After-sales Service Provided	Engineers available to service machinery overseas
Warranty	12 Months	Weight	2600KG
Dimension(LWH)	220021002200mm	Voltage	220V/380V
Condition	New	Power(W)	5.5kw

Product Description

(1) Base, sliding block, working bench, vertical column , spindle box and other main basic parts adopt HT300 cast iron; base is box type structure with symmetric compact and reasonable structure which ensures the basic parts of the high rigidity and bending resistance performance.

(2) The guide rail of X, Z, Y axis are use Taiwan HIWIN company's heavy load linear ball guide, has the advantages of fast speed, Eliminate intermittent creep, high rigidity, low friction, low noise , low temperature rise and so on. Using automatic forced lubrication, it can improve the accuracy of machine tools.

(3) The feed of X, Y, Z direction adopts the inner loop preloading large-lead ballscrew with double nut so it is of high feed speed. The drive motor connect with screw straightly via elastic coupling. The feed servo motor passes power to the high precision ball screw directly.

Technical parameter

ITEM	UNIT	VMC350L	VMC420L	VMC460L	VMC550L	VMC600L	VMC650L
Table size	mm	690*230	780×260	800×300	800×320	800*360	900×360
Load capacity	KG	150	150	200	300	350	400
T slot		3-16-63	16*3	3-14*80	14*3	3-14*115	18*3
X-axis travel	mm	350	420	460	550	600	650
Y-axis travel	mm	260	260	320	340	400	380
Z-axis travel	mm	350	420	460	460	500	460
Distance from Spindle center to table	mm	90-440	90-500	900 - 550	100-560	100-600	100-560
Distance from Spindle center to column slide way	mm	294	315	395	410	430	460
Tool shank		BT30	BT30	BT30/BT40	BT40	BT40	BT40
Spindle speed	RPM	10000	10000	10000	8000	10000	8000
Spindle motor power	KW	2.2/3.7	2.2/3.7	3.7	5.5	5.5	5.5
Max. diameter of tool	mm	30/80	φ50/φ100	80/120	φ80/φ150	120*200	φ80/φ150
Max. length of tool	mm	120	150	200	300	350	300
Max. weight of tool	KG	3	4	6	6	8	6
X/Y -axis rapid moving speed	mm/min	20000	20000	20000	20000	30000	20000
Z-axis rapid moving speed	mm/min	20000	20000	20000	20000	30000	20000
feed rate	mm/min	1-4000	1-4000	1-4000	1-10000	2.5-3000	1-10000
positioning accuracy	mm	0.02	±0.01	±0.012	±0.01	0.015	±0.008
repeated positioning accuracy	mm	0.01/300	±0.005/300	±0.007	±0.004/300	0.0075	±0.003/300
Out dimension	m	1.521.31.8	1.651.61.9	1.81.752	2.12.052.1	2.22.12.2	2.352.12.15
Machine weight	kg	1200	1700	1900	2300	2600	3000

Our Company

Jinan Hankui international trade co., ltd, which is the subsidiary corporation of Shandong Hunk precision machinery Co., Ltd., is a CNC machine tools company, located in the beautiful capital Jinan city, integrated with manufacturing, processing and sales. It was set up by the former Jinan Machine tools factory employees. It has a subsidiary corporation Jinan HANKUI International Trade Co., Ltd.

We have a number of R&D persons and technicians who have more than 20 years experience of machine tool design and assembly. We have mastered the advanced machine tool technology and were dedicating to service customers domestic and abroad and welcomed deeply.

Now our products have a large market share and have a high popularity in domestic. Sales and services network have been established in many provinces and cities. Our products have been sold to America, South East Asia, Russia and Middle East countries with high reputation.

We have passed the ISO9001:2008 international quality management system authentication. “Honest and trust, Customer ahead, pursuit of excellent”, we devoted to provide high quality performance CNC products and metal products to you. Welcome to visit our factory.

Packing & Delivery

FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available, We need your machines running in order to keep your business running.

Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.

Q: What sales terms do you have?
A:T/T, L/C,West Union.

Q: What kind of controls/Parts do you use on your machines?
A: AMS, OMRON, Schneider, Siemens, and ASK,ABBA,OPTIMA(ITALIA),HSD

Q: What is your delivery time?
A: Depending on the type of machine, duration of 10 days to 45 days from date of order.

Q: Do we receive any updates while machine is in the manufacturing process?
A: Yes.Regular updates on progress will be sent to you.
