XY-150 Hydraulic Core Drilling Rig Core Drilling Rig for Hard Rock
US$ 5700 - 6200
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HuaXia Master
Place of Origin:
China
Model Number:
XYC-200A
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao
Delivery Detail:
10 days
Related Products
-
XY-180 Hydraulic Core Drilling Rig Core Drilling Rig for Hard RockUS$ 5700 - 6200MOQ: 1 Set -
Core Sample Drilling Rig XY-200 Hydraulic Core Drilling RigUS$ 5700 - 6200MOQ: 1 Set
-
XY-3 Hydraulic Core Drilling Rig Core Drilling Machine PriceUS$ 5700 - 6200MOQ: 1 Set
-
XYX-3 Wheeled Hydraulic Core Drilling Rig Wheels Portable Drilling MachineUS$ 5700 - 6200MOQ: 1 Set
-
XYX-3 Wheeled Hydraulic Core Drilling RigUS$ 5000 - 6000MOQ: 1 Set
Brand Name
HuaXia Master
Place of Origin
China
Model Number
XYC-200A
Weight
1600kg
Application
water well and exploration
Max. Drilling Diameter
260 mm
Drill Type
Other, rotary drill
1. Applications of XY-150 core drilling rig
l geological survey
l geophysical exploration
l road and high-rise building foundation exploration
l water wells
l blasting holes and other drilling projects
2. Parameters of XY-150 core drilling rig
Drilling depth(m) |
150 |
Maximum opening diameter（mm） |
219 |
The final hole diameter（mm） |
73 |
Rod diameter（mm） |
42/50 |
Spindle speed (r/min) |
140/295/470/790/1010 |
Spindle stroke（mm） |
450 |
Hoisting capacity (kn) |
14 |
Steel wire diameter（mm） |
9.3 |
Maximum pressure (mpa) |
1.2 |
Working pressure (mpa) |
0.7 |
displacement（l/min） |
150 |
Hydraulic pump pressure (mpa) |
1.2 |
Hydraulic pump rotation speed (r/min) |
1800 |
Matched driving power (diesel engine and motor) |
S1105 diesel engine and 11kw motor |
