Help CenterMetal Housing Car Camera for Truck/bus/car
Related Products
-
2013 Best Hot Front and Back View Camera for Reversing and RearviewUS$ 18.28 - 28.66MOQ: 100 Pieces -
Metal Housing Infrared Light Car Camera WaterproofUS$ 18.28 - 28.66MOQ: 100 Pieces
-
2013 Best Hot Waterproof CCD Car Reverse Camera With ir Night VisionUS$ 18.28 - 28.66MOQ: 100 Pieces
-
2013 Best Hot CCD/CMOS Vehicle Front View CameraUS$ 18.28 - 28.66MOQ: 100 Pieces
-
2015 Best Hot Cheap Mini CCD Car Rear View CameraUS$ 18.28 - 28.66MOQ: 100 Pieces
Specifications
1)Waterproof reversing camera for car2)Very Low Min.Illumination
3)High Quality,Good Price,Good Services
4)cmos/ccd optional
Shenzhen Topsee Technology Co., Ltd. was established in 2006.We are professinal OEM/ODM automotive reversing system manufacturer for 6 years,involved in items of Designing,Research and Development,Manufacturing and Export,we are aiming supply high quality products to customers all over the world.
1.Technical Specifications and more photo pictures
CAMERA:
| Specification | default | optional | optional |
| Image Sensor | 1/4 inch PC1030 | Sharp CCD | SONY CCD |
| TV System | NTSC/PAL | NTSC/PAL | NTSC/PAL |
| Lens Angle | 170° | 170° | 170° |
| Resolution | 380 TV line | 420TVLine | 480TVLine |
| Effective Pixels | PAL:582H×492V | PAL:720H×576V | PAL:720H×576V |
| NTSC:510H×492V | NTST:720H×480V | NTST:720H×480V | |
| AGC | Auto | Auto | Auto |
| BLC | Auto | Auto | Auto |
| S/N Ratio | > 45dB | > 45dB | > 45dB |
| Work Current | <70mA | <70mA | <70mA |
| Work Voltage | 12±10% | 12±10% | 12±10% |
| Operating Temperature | -20°C~50°C,RH95%MAX | -20°C+50°C,RH95%MAX | -20°C+50°C,RH95%MAX |
| Storage Temperature | -30°C~60°C,RH95%MAX | -30°C+60°C,RH95%MAX | -30°C+60°C,RH95%MAX |
| Minimum Illumination | 1.0Lux/(0Lux with led on) | 0.5Lux/(0Lux with led on) | 0.5Lux/(0Lux with led on) |
| Water-proof | IP67 | IP67 | IP67 |
Main feature:
1.car revering distance reference line(optional)
2.Mirror image and oringal image(optional)
3.High resolution rearview camera that works at night or day
4.Waterproof, Shockproof ,antifog ,high temperature resistance,humidity resistance,high definition long-lasting outdoor using camera
5.Simply pair it with a LCD screen ,DVD Player,sunvisor,rearview mirror
Installation:
Connect the yellow video output connector to terminal display device.
Connect the black power input connector to power output device.
Accessories:
* 1.5 meters DC line.
* Manual.
2.certification
3.More details for your reference
♥ MOQ: MOQ =100pcs,first business sample is ok,and we charge $10.00sample fee.
♥ Trade Terms: EXW(FOB,CIFetc.are available too)
♥ shippment:TNT.FEDEX.DHL.UPS.EMS
♥Lead time:5-7days according to model and quantity.
♥Payment Terms: T/T,West Union,paypal
♥warantee:one year after shippment
