Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Processing Machinery Parts > 10meshx1.1mm Stainless Steel Mesh Strong Weaving Machine With Good Price
10meshx1.1mm Stainless Steel Mesh Strong Weaving Machine With Good Price
US$ 10000 - 30000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
shijiazhuang highui
Place of Origin:
China
Model Number:
China CNC shuttleless machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin ,china
Delivery Detail:
45 days
Related Products
-
1300MM WIDTH SHUTTLELESS WEAVING MACHINE PriceUS$ 10000 - 30000MOQ: 1 Set -
2 Mtr Stainless Steel Wire Mesh Weaving Machine PriceUS$ 10000 - 30000MOQ: 1 Set
-
Stainless Steel Reverse Dutch Mesh Weaving MachineUS$ 10000 - 30000MOQ: 1 Set
-
Shuttleless Weaving Machine Professional ManufacturerUS$ 10000 - 30000MOQ: 1 Set
-
Stainless Steel Big Wire Coarse Mesh Window Screen Weaving MachineUS$ 10000 - 30000MOQ: 1 Set
Brand Name
shijiazhuang highui
Place of Origin
China
Model Number
China CNC shuttleless machine
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
Send us your inquiry with below information:
1. Mesh:?
2. Mesh wire diameter:?
3. Mesh roll width?
4. How many sets you need?
With your mesh which you want to produce, we will offer you right machine
| Model | Width MM |
Opening density (Mesh) |
Wire diameter(mm) | Rotating speed of crank shaft (r/minute) |
Motor power(KW) | Weight(T) | Outside size(mm) |
| ZWJ1300B | 1300 | 60-350 | 0.01-0.14 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZWJ1300D | 1300 | 16-120 | 0.14-0.30 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZWJ1600B | 1600 | 60-350 | 0.01-0.14 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZWJ1600D | 1600 | 16-120 | 0.14-0.30 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZZWJ-1300/1600 Heavy machine | 1300/1600 | 2-16 | 0.1-0.55 | 35 | 5.5KW380V,50HZ | 8-16 | 3500x4200x2500 |
| ZZWJ-1300/1600 BIG Heavy machine | 1300/1600 | 2-20 | 0.5-1.6 | 35 | 5.5KW380V,50HZ | 8-16 | 3500x4200x2500 |
| Above is just as your reference tell us the mesh, wire diameter, width which you frequently weave in whole year We will make the machine based on this, then it will save you cost: machine purchasing cost, material weaving waste cost, power consumption cost | |||||||
| For the Mesh width you weave , we not only do 1300 /1600, we also can do 1000, 2000, 3000, 4000, it is based on your request | |||||||
|
Different country, the power pressure is different, like India–415V or 440-220 V So this is adjustable by your country’s need | |||||||
| What we focus on is detailed and real request, then it will be helpful for us to give our best valued suggestion | |||||||
Send Inquiry to This Supplier
Mrs. shijiazhuang highui
Sales Manager
Shijiazhuang Highui Machinery Co.,ltd
Shijiazhuang, Hebei, China
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer
Year Established
1981
Annual Export Value
US$2.5 Million - US$5 Million
Port of Shipment
Tianjin
