Automatic Tapping Machine Manufacturer and Production Line

Automatic Tapping Machine Manufacturer and Production Line photo-1
US$ 1,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
DELIN automatic tapping machine
Model Number:
DELIN automatic tapping machine
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name DELIN automatic tapping machine
Model Number DELIN automatic tapping machine
Condition New
After-sales Service Provided Engineers available to service machinery overseas

Specifications

automatic tapping machine:
1. human-computer interface.
2. be applicable to valve, water tag, hardware.

  automatic tapping machine  manufacturer and production line :



Introduction automatic tapping machine   :

     DL-361 automatic tapping machine      which is vertically divided, semi-automatic, with the die upturned. Core is taken out manually. The core shooter is applicable to valve, water tag, hardware fittings, hydraulic pressure and small workpieces of variety cores in the air-powered industry.

    It is used to produce furan resin series heat core box sand, urea resin series heat core box sand and pre-coated sand core-making.



automatic tapping machine    Characteristics & Applications:



    (1)With the human-computer interface, imported high quality electrical and air controlled components, precise and reliable control and convenient operation are guaranteed.

   (2) Manually operated with two functions of unicycle and multi-cycle.

   (3) The shooting head rotates for 50° to receive sand,  it is easy to clean the shooting hole manually.

   (5) The machine can be plainly moved as a whole.

   (6) Die adjustment margin is set to make it easy to use different dies and lower the requirements of die exterior physical dimension.



automatic tapping machine     tapping machine  Technical data:

model

Automatic core shooting machine

The maximum qualitative properties of the sand core

6Kg

Maximum core box dimension

400×280×200

Heating power

9.6Kw

Productivity

40-100box/hour

Compressed air pressure

0.6Mpa

Die-opening stroke

<300mm

Motor power of the sand hopper

0.25Kw

Conveying speed

72mm/s

Conveying belt angle of rise

2°- 4°

Maximum stroke of the core-pulling guide rod

150 mm



        automatic tapping machine manufacturer and production lineautomatic tapping machine manufacturer and production line



 automatic tapping machine manufacturer and production lineautomatic tapping machine manufacturer and production lineautomatic tapping machine manufacturer and production lineautomatic tapping machine manufacturer and production lineautomatic tapping machine manufacturer and production lineautomatic tapping machine manufacturer and production line







Being perfect is a dream.basend on th eprinciple of perfection.

To give Best service to all customers.
