DESCRIPTION
The SZ P2-S 4Axis is a large format free standing machine with welded steel frame, smooth linear rails with HIWIN/PMI Linear rails and guide blocks. The machine bed is manufactured with a T-slot aluminium extrusion making clamping of parts quick and easy. With traveling speeds up to 25000mm/min and working speeds of15000mm/min this is a truly versatile machine for the budget conscious.
STANDARD CONFIGURATION• Working area: 1500mm*3000mm*400mm, PVC table ( with Aluminium profile)
• Drive System: YSAKAWA servo motor
• 6 kw air cooled CHANGSHENG spindle
• T-slot PVC table (with Aluminium Profile)
• HIWIN/PMI linear rails
• NC-STUDIO controller system for stand alone operation. Computer based
• Z zeroing Tool sensor
• One starter set of engraving tools
• Inverter：TaiWan Delta Inverter
• Electronic Parts：German Schneider Electronic Spare Parts
• Switch gear：Japanese OMRON Switch
• Cable：Germany LAPP Highly flexible towline-only Cable Imported fire-resistant double-sheathed, can be bent 300000 times
• Voltage: 3PH 380V 50/60HZ
• Package: plywood case
• SYNTEC 6MB control system
• Italian HSD Spindle /7.5KW air/water cooling spindle
• Oil Mist Cooling System for engraving non-ferrous metals
• Dust collection system
• Size Options: 1300*2500*400MM / 2000*4000*400MM / Custom made
• Z-axis size : 400MM / 600MM / 800MM / 1000MM / Custom made
TECHNICAL PARAMETERS| SZ P2-E |
SZ P2-1325E |
SZ P2-1530E |
SZ P2-2030E |
| Working area | 1300x2500x400mm | 1500X3000X400mm | 2000X3000X400mm |
| Table size | 1360x2550mm | 1560x3100mm | 2060x3100mm |
| Transmission | X,Y with Rack and Pinion Z with Ball screw,HIWIN Linear Rails and guide blocks.(Option:THK-Lubricated for life linear rails and guide blocks) |
||
| Table structure | Vacuum table in zones(Option:T-slot&vacuum combination table) |
||
| Spindle | Chinese 6kw ATC spindle(Option:6kw Italian HSD spindle) |
||
| Spindle speed | 0-24000RPM | ||
| Spindle | MAX travelling speed:25000mm/min |
||
| MAX working speed:15000mm/min | |||
| Driver and Motors | YASKAWA servo motor and driver |
||
| Working voltage | AC380V/3PH/50HZ(Option:AC220V/3PH/50HZ/60HZ) |
||
| Control system | NC-STUDIO-PC |
||
| Net weight |
1800KG | 2500KG | 3000KG |
| Gross weight | 2050KG | 2750KG | 3250KG |
|
|
|
|
| 3D model | Side hole | ±180° material |
