Jamag’s original 10-year manufacture of neodymium magnets diametral , our offer for anyone who is looking for neodymium small magnets, and more custom made sizes are available !
1, More Direct Information of neodymium magnets diametral
1.1 The types of magnet we can supply
Neodymium magnet (also known as NdFeB, Nd2Fe14B, NIB or Neo magnet), the most widely used type of rare earth magnet and the world's largest permanent energy product materials.In 1982, Sumitomo Special Metals Sagawa live (Masato Sagawa) found neodymium magnets. It is the most commonly used in electronic products, such as hard drives, mobile phones, headsets, and battery-powered tools. To prevent corrosion damage, the need to make the magnet material surface protection treatment, for example, gold, nickel, zinc, tin plating, and the surface coating such as epoxy resin.
1.2 The size of magnet we can supply
1.3 The coating of magnet we can supply
1.4 The Grade of magnet we can supply
1.5 Magnetised direction
1.6 Physical performance of magnet
Physical Performance of Sintered Neodymium Magnet | ||
Parameter |
Unit |
Reference |
Density |
g/cm3 |
7.4-7.6 |
Vickers Hardness |
HV |
500-600 |
Resistivity |
μΩ·m |
1.4-1.6 |
Compressive Strength |
MPa |
1000-1100 |
Tensile Strength |
MPa |
80-90 |
Thermal Conductivity |
W/(m.K) |
8-10 |
Young's Modulus |
Gpa |
150-200 |
Vertical Thermal Expansion Coefficient |
10-6/K |
1-3 |
Parallel Thermal Expansion Coefficient |
10-6/K |
3-4 |
1.7 Great engineers manufacture great magnet product !
1.8 Detailed Four Step High quality magnet board with integrating quality control !
STEP 1: After sintering, the mould comes out. Test the size, tolerance and the property (BH(max), Br, Hcj, Hcb) of the mould, only the qualified products turn to next step.
Magnet performance standard: GB/T 13560-2009
Quality control: MIL STD 105E=ISO 28591=NF X 06 022, LEVELⅡ
STEP 2: After grinding, inspect the size and tolerance of the magnet with precision before coating, only the qualified products turn to next step.
STEP 3: After cutting the thickness, examine the tolerance of thickness, guass and pull force, only the qualified products turn to next step.
STEP 4: Recheck the coating, size and tolerance, surface of the magnet, exclude the unqualified (damaged, bad coating) pieces, then come to magnetizing and packaging.
2 More correspond Information of neodymium magnets diametral
2.1 Package
3 Business and Economic Correspond Factor
3.1 Sample Policy
3.3 Payment Terms
Fast payment below
4 Our Service
Why Choose Jamag as your magnet product supplier: Fast reply, professional advise.
1) Prompt reply time: Office time (GMT+8), reply in 3 hours
Off office time, reply in 12 hours
2) Fast and strict Quality control and Delivery control
3) Super Strong Magnet, 400 types in stock, serve for above 1000 customers, specialized in N35, N38 etc.normal grade magnets and high performance small size magnets.
4) ALIBABA qualified “Manufacture and Trading company”. 10 year magnet manufcture experience, 4 year magnet export experience.
5) Strong development capability of magnet with 3M glue, stainless steel hardware products, magnet with plastic products and other custom made magnet assembly.
6) Train service and timely feedback for mass production.
