Help Center3V Pressure Transmitter Low Consumption Pressure Transmitter
Related Products
-
3V Pressure Sensor Battery Supply Pressure SensorUS$ 1 - 1MOQ: 1 Unit -
GPRS Ultrasonic Level Sensor Ultrasonic Transducer Price Waterproof Ultrasonic TransducerUS$ 1 - 1MOQ: 1 Unit
-
GPRS Ultrasonic Level Sensorultrasonic Distance Sensor 0-5m Level SensorUS$ 0.4 - 0.4MOQ: 1 Unit
-
Gsm Rtu Sms Controller Gsm Sms Modbus Rtu ControllerUS$ 1 - 1MOQ: 1 Piece
-
Wireless Pressure Sensor Remote Pressure Sensor Lora Pressure SensorUS$ 1 - 1MOQ: 1 Unit
Based on piezoresistive silicon technology, IP10 silicon pressure transmitter uses isolated stainless steel diaphragm as sensing element. This product is fully tested by computer automatically, and trimmed by laser for zero and sensitivity in a wider temperature range. Its amplifier circuit is built in stainless steel housing, to transform sensor signal into standard output signal. This transmitter features integrated construction, rigid and robust, high measuring accuracy, good long term stability, and is suitable for pressure measurement in general industry applications.
l 3V supply
l 0.2-2.7V output
l 0.5% Overall accuracy
l piezoresistive silicon technology
l ]high accuracy, high resolution
l digital chip compensation
parameter: |
Min. |
Typ. |
Max. |
Unit |
|
Accuracy(include linearity, hysteresis and repeatability ) |
-0.25 |
|
+0.25 |
%Span |
Long stability(1year) |
-0.25 |
|
+0.25 |
%Span |
Total tolerance |
-1.0 |
|
+1.0 |
%Span |
Compensation Temp. |
-20 |
|
+85 |
℃ |
Working Temp. |
-40 |
|
+125 |
℃ |
Storage Temp. |
-40 |
|
+150 |
℃ |
Burst Pressure |
5X |
|
|
Rated |
Virbration |
-20 |
|
+20 |
g |
Shock |
50 |
|
|
g |
Recycles |
10 |
|
|
million |
Overload Pressure |
2X |
|
|
Rated |
Weight |
82 |
|
|
grams |
Compatible Media |
|
304/316 |
|
|
|
Contact the factory for special model
|
|
|
|
|
