Home > Products > Glass Laminating > windshield Glass laminating Line for Bus Glass
windshield Glass laminating Line for Bus Glass
- 0 Piece / Pieces per Month
- shanghai
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | Lever | Place of Origin: | China | Model Number: | LV-BL Series |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 12 months |
Condition: | New | Voltage: | 380KVA | Machine Type: | Glass Laminating Machine |
Product Description
windshield Glass laminating Line for Automobile front Glass
Product Description
1. Machine Application:
Continuous Thermal Bending Furnace is a special plant used to produce the laminated windshield for the car or bus. It is the first processing machine in the whole windshield production line.
The glass produced by this machine is the thermal bent glass.
2. Supply Scope:
2.1. Loading system
2.2. Pre-heating chamber(s)
2.3. Heating chamber(s)
2.4. Pre-forming chamber(s)
2.5. Forming chamber(s)
2.6. Annealing chamber(s)
2.7. Cooling chamber(s)
2.8. Unloading system
2.9. Electrical & control system
2.10. Technical documents
3. Machine Main Features:
3.1. The whole process is controlled and monitored by computer.
3.2. Key control elements are from world famous company (such as Siemens, Omron, ABB etc.) to insure reliable performance,
3.3. The monitoring system which object the glass status in forming area can ensure low labor intensive and good working environment.
3.4. Different type of glass can be loaded in different wagon. Computer control system identifies wagons automatically and bends glass according to pre-setp.
3.5. Each heating unit in the forming zone can be controlled individually, which ensure flexible heating. The forming process can be interfered manually.
3.6. Powerful software package, comfortable man-machine interface, complete self-check system insure stable and reliable running. And the parameters can be changed on-line.
3.7. The annealing section guarantees the performance of the products, the exhaust device of the cooling layer can accelerate the cooling speed and improve the efficiency.
3.8. Conveyors are equipped with proximity switch, which ensures accurately and reliably running.
3.9. The wagon is of tank structure can insure lower heating consumption. The observe windows are Quartz glass, which resist higher temperature and damage.
3.10. It is easy to make moulds with the lower cost.
Product Specification/Models
LV-BL
1500x800mm
1500x900mm
1600x900mm
2000x1000mm
Application
Automotive windshield glass
windscreen glass
