Water cooled scroll chiller closed type

Name: Water cooled scroll chiller closed type
Brand: SENLH
Availability: InStock

FOB Price

USD $5500 - $6500 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SENLH	Place of Origin	China
Model Number	MG-20W	Type	Water-Cooled
Certification	CE	After-sales Service Provided	Engineers available to service machinery overseas
Warranty	1 year	Weight	820kg
Dimension(LWH)	210010001700mm	Voltage	3PH-380/415/440/460/480V-50/60Hz
Condition	New	Cooling Capability(kw)	60.8kw

Industrial Water Cooled Scroll Chiller

Specification

Model		MG-3W	MG-5W		MG-6W	MG-8W(D)	MG-10W(D)	MG-12W(D)	MG-15W(D)	MG-20W(D)	MG-25W(D)	MG-30W(D)
Cooling capacity	Kcal/h	8084	12384		14448	20124	27004	29326	39560	52288	59770	79120
Cooling capacity	kw	9.4	14.4		16.8	23.4	31.4	34.1	46	60.8	69.5	92
Input Power	kw	3.3	5.3		6.2	8	9.8	11.6	15.1	19.6	22.7	29.4
Power supply		3PH-380/415/440/460/480V-50/60Hz
Refrigerant	Type	R22/R407C
Refrigerant	Control type	Thermostatic expansion valve
Compressor	Type	Hermetic scroll type
Compressor	Power(kw)	3	4.5	5.4		7.2	9.1	10.8	13.6	18.1	21.2	27.2
Evaporator	Type	SS Tank with coil or Shell and tube or Brazed plate heat exchanger
	Water flow(m³/h)	1.6	2.5	2.9		4	5.4	5.8	7.9	10.4	11.9	15.8
	Capacity(L)	50	70	70		120	200	200	270	350	350	450
	Fitting pipe(mm)	DN25	DN25	DN25		DN32	DN32	DN32	DN40	DN40	DN50	DN65
Condenser	Type	Shell and tube
	Water flow(m³/h)	2.12	3.25	3.81		5.25	6.94	7.7	10.22	13.53	15.55	20.43
	Fitting pipe(mm)	DN25	DN25	DN25		DN32	DN32	DN32	DN40	DN40	DN50	DN65
Chilled water pump	Type	Centrifugal water pump
	Power(kw)	0.37	0.75	0.75		0.75	0.75	0.75	1.5	1.5	1.5	2.2
	Lift(m)	20	20	20		20	20	20	20	20	20	20
Dimension	L(mm)	1200	1300	1300		1400	1560	1560	1800	2100	2100	2200
	W(mm)	600	650	650		800	850	850	1000	1000	1000	1160
	H(mm)	1000	1200	1200		1400	1500	1500	1600	1700	1700	1900
Weight	kg	130	150	165		300	430	500	735	820	900	1150

Water chiller factory

Water chiller in various applications
