Efficient YF1700 1.7m DX5 Eco Solvent Indoor/outdoor Printer

Name: Efficient YF1700 1.7m DX5 Eco Solvent Indoor/outdoor Printer
Brand: YIFANG
SKU: 158426104
Availability: InStock

US$ 4,500 - 4,700 MOQ: 1 Set

Key Specifications

Condition:

New

Plate Type:

Other, ink jet printer

Place of Origin:

Guangdong, China

Shenzhen Mingyang Digital Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Other, ink jet printer

Place of Origin Guangdong, China

Brand Name YIFANG

Model Number YF1700S

Usage Paper Printer

Automatic Grade Automatic

Voltage 110V/220V

Gross Power 700W

Dimensions(L*W*H) 2500*860*1280mm

Weight 300kg

Certification CE

After-sales Service Provided No overseas service provided

Product description

Support double Epson DX5 print head (picture 1)

Equipped with automatic print head maintenance station (picture 2)

Positive ink supply system with 1500ml/color capacity ink tank (picture 3)

Industrial vacuum table keep high resolution printing quality (picture4)

Perfect Color Presentation

Perfect brushless Servo Motor with DSP digital controlling technology

Original Industrial HIWIN non-noise linear rail

High resolution media feeding system, more accurate

LED lighting system, better operation in dark environment

High-tech on printing control, less ink consumption

Specification:

Item model	YF1700S
Print head	Piezo Technology Epson DX5
Resolution	Up to 1440dpi Visual Resolution
Print head number	1pcs
Maximum Print Width	1700mm
Print Resolution/ Speed (sqm/h)	Production (4pass): 14
	Standard (6pass): 13
	High resolution (8pass): 10
Ink type	Eco-Solvent Ink/Sublimation Ink/Dye Ink/Reactive Ink
Ink supply system	Positive ink supply system with cleaning function , 1500ml/c ink tank
Color	Double CMYK
Media width	1700mm
Media thickness	1.5mm (1.5mm-5mm adjustable)
Media Roll Diameter(I/D)	55mm or 76mm/ <200mm
Max media weight	100kg
Media type	Vinyl, Flex Banner, Mesh, One Way Vision, Paper, Textile, Wall Paper, Coated Banner, Canvas, Film, Lint-free Cloth, Photo Paper etc.
Data Communication	High speed USB2.0(480m/s)
Image data format	BMP, TIFF, EPS,PDF, AI, JPEG
Rip	Ultra Print V4.4 YIFANG Version
Operation environment	Power supply: 220v(±10%), >10A,single phase
	(Temperature): 18℃-35℃
	(Humidity): 40%-70%
Power Consumption	700W
Machine Size (L x W x H)	2.5 x 0.86 x 1.28 m
Package type/size	Wooden box/ 2570720750 (mm)
Gross Weight / Net Weight	300KG/225KG
The exact configurations of equipment are subject to real machine
Motor	Perfect Brushless Servo Motor
Linear Rail	Original Industrial HIWIN non-noise linear rail
Heating System	Digital Control Pre & Back Heater
Drying System	Optional
IR Drying System	Optional
Media Handling	Roll to roll handling
Take-up System	Optional: single/double driven automatic take-up
