Cooling vest with fan / air conditioned clothes
1. You will be comfortable in the hot summer.
2.Always sweat is very uncomfortable, work efficiency is low. If you have the air conditioning clothing, your work will be better.
3. 7.4V battery don’t have radiation. The skin does not dry for a long time wear.
4.Cooling clothing work time:8-48 hours.
Charging time:3.5hours
4 grades adjustable wind speed
5. Removing the cooling system can be washed.
1.References for battery working time:
The tested battery capacity is 4400mAh.
The working time for the fourth gear is 8 hours and forty-five minutes.
The working time for the third gear is 12 hours and ten minutes.
The working time for the second gear is 23hours and 18minutes.
The working time for the first gear is 59hours and 52 minutes.
2.Manual:
1.Starting and instruction
Press ON/UP to check the battery capacity left, press the button for1.5second to start the cooling system. It normally shows the fourth gear.
2.Shutdown
Press the key OFF/DOWN 1.5 second, The digital Led will be putted out.
When it is unloaded, the battery will be automatically powered off in 5 second.
When the battery is exhausted, it will be also shutdown in 2s.
3.The power instruction for discharging
There are 10 grades of the battery capacity , using number from “0”to”9”to show. When
The number “0”flashes,it means lower power, and the battery will be shut down soon. and
The number”9”means the fully charged.
4.Charging instructions
After the charger connected with the DC connector, the digital tube showing
charging condition and the decimal point will remain flashing. when it
get to the full power, it shows number “9” ,and meantime the decimal point will not flash
again . The degree of the power depends on the signal light, when the charger light shows green, it means the power is fully charged.
5.Short circuit over loading protection:
When the output interface short circuit, the battery will automatically go into
The protected condition. It needs to charge to activate the battery.
6.The ability for loading
The maximum output voltage is 2A.
3. Functional parameter reference form are the following:
Gear |
Battery showing number |
Output voltage |
4 |
4 |
7.2V |
3 |
3 |
6.0V |
2 |
2 |
4.5V |
1 |
1 |
3.0V |
4.The specification of the charger and battery:
4.1: Charger: Input AC100V-240V,Output DC8.4V-10V.
4.2:Battery : 7.4V 4400Mah,
4.3,charging time:3-4 hours
5.Notes for using battery:
If you do not use properly, the battery will leak out or explode. So please obey the rules
following when you use the battery.
1.Before you change the battery, please first turn off the power of the battery.
please use our Special-purpose battery to charge.
2.Do not make the battery short circuit or disassemble the battery, or take the battery
out and damage the surface of the battery.
3.Do not put the battery into the water or touch any water.
4.Do not put the battery in the high temperature, keep away from fire too.
5.Please keep the battery in the battery box when you carry it, do not put it with metal items together.
6.If you find there is something wrong or abnormal, please stop using.
