HIG servo motor economy semi automatic flat labeling machine
Servo motor economy semi automatic flat labeling machine
This servo motor economy semi automatic flat labeling machine is applicable for all kinds of flat objects such as food, chemical, pharmaceutical, cosmetic, stationery, CD disc, carton, box and various oil kettles etc. This servo motor economy semi automatic flat labeling machine is for flat side labeling. flat surface labeling machine
Features
| Operation | Manual |
| Material | Labeling machine's main body is made of SUS304 stainless steel |
| Configuration | Our labeling machines adopt well known Japanese, German, American, Korean or Taiwan brand parts |
| Flexibility | Client can chose to add printer and code machine; can chose to connect with converyer or not. |
Technical Parameters
| Name | semi automatic flat labeling machine |
| Labeling Speed | 20-200pcs/min |
| Height of Object | 30-200mm |
| Thickness of Object | 20-200mm |
| Height of Label | 15-110mm |
| Length of Label | 25-300mm |
| Label Roller Inside Diameter | 76mm |
| Label Roller Outside Diameter | 350mm |
| Accuracy of Labeling | ±0.8mm |
| Power Supply | 220V 50/60HZ 0.75KW |
| Gas Consumption of Printer | 5Kg/m2(if add coding machine) |
| Size of Labeling Machine | 1600(L)×550(W)×1600(H)mm |
| Weight of Labeling Machine | 150kg |
Operating flow chart
- Port: Shanghai
- Packaging details: wooden case export packing
- Delivery detail: Normally 12-15 days after receipt of payment
Higee Machinery- Labeling Machine Manufacture! Labeler solution expert!
We are not only servo motor economy semi automatic flat labeling machine manufacture in providing different function Labeling Machine with good experience for many years, but also the professional solution provider to give the most suitable labeling proposal according to client’s product shape or size either regular or irregular, either use adhesive paper label or plastic sticker label. Our machine is mainly made of good quality SUS304 stainless steel and equipped with well known Japanese, German, American, Korean or Taiwan brand parts. Either the automatic or semi-automatic Labeling machine is smart and durable labeling equipment which is quite easy for your operation and maintenance. This servo motor economy semi automatic flat labeling machine is widely used in such industries as food, medicine, cosmetics, electronics, chemical etc. semi automatic flat labeling machine
Trust us, Higee Labeling Machinery, Your good choice! Quick response to your request!
1. Offer you professional labeling sulution according to your specific labeling requirements.
2. Supply you high quality labeling machine after placing order.
3. Try to make the delivery time as short to meet your needs.
4. Provide you lifelong free technial support after you receiving our machine.
1. What kind of labeling machine do you have?
Dear Customer, we have automatic and semi-automatic labeling machine for round containers and flat surface. Some model for one label and others for two labels or even more. And we can design the machine according to your specific labeling situation.
Thus, pls fell free to send us your labeling requirements, we'll provide you satisfying labeling solution.
2. Could we add coding machine to print date and lot No.?
Yes, you can chose to add coding machine to print the letters and No. you want.
It's hot stamp and can print at most three lines.
3. What information should we supply to check the suitable model?
Pls send us picture of your container and label, as well as the container and label size.
Pls also tell us what kind of label you use, if possible. (For exampe, self-adhesive, could glue, hot glue, etc. whether the label are in roll or pieces.)
Then, we'll let you check the suitable model.
