SJ-320B/D Pe Film Shrink Packing Machinery

SJ-320B/D Pe Film Shrink Packing Machinery photo-1
US$ 6,500 - 8,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Commodity, Medical, Chemical, Textiles, Other, Food, Beverage, Commodity, Medical, Chemical, Textiles, Pe film shrink packing machinery
Packaging Type:
Cans, Bags, Film, Pouch, Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food, Beverage, Commodity, Medical, Chemical, Textiles, Other, Food, Beverage, Commodity, Medical, Chemical, Textiles, Pe film shrink packing machinery
Packaging Type Cans, Bags, Film, Pouch, Case
Packaging Material Plastic, Paper
Automatic Grade Automatic
Driven Type Electric
Voltage 220V 50/60HZ
Place of Origin Shanghai, China
Brand Name Higee
Model Number SJ-320B Pe film shrink packing machinery
Weight 500KG
Dimension(L*W*H) 3900x950x1500mmq
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Double transducer control
2.Human-machine operation
3.Pe film shrink packing machinery
4.Automatic PLC system

        Pe film shrink packing machinery SJ-320B





Application:

This Pe film shrink packing machinery is applicable for packing various solid regular objects, such as biscuits, bread,

instant noodle, ice cream,moon cake, candy, medicine,commodity,hardware parts, boxes or trays etc.



Parametre technique about Pe film shrink packing machinery:

Model

SJ-320B/D  Pe film shrink packing machinery

Packing Speed

35-180 bag/min

Bag Size

L(80-330)mm × W(30-145mm × H(5-65)mm

Film Width

80-320mm

Packing Material

OPP/CPP,PT/PE,KOP/CPP,ALU-FOIL

Dimension

(L)3900mm×(W)950mm×(H)1500mm

Heating Power

2.1KW

Motor Power

0.55+0.75KW

Total Power

3.4KW

Overall Weight

600kg





Specifications about Pe film shrink packing machinery:

1. No need manually set bag length. During operation the machine can automatically self-detect and set the bag length.

2. Double transducer simplifies mechanic gearing. Pe film shrink packing machinery is easy to maintain, little wear and long life.

3. The main control circuit takes the single chip developed by our own company. Touch screen display, controlled by transducer.

    Perfect interface between operator and machine. Integrated, direct and convenient operation.

4. The packing speed and bag length is controlled by double transducers. CVT changes speed in a wide range.

    Well match with the former procedure on production line.

5. Highly sensitivity photoelectric device tracking automatically and accurately.

6. Independent temperature control for each seal to make the seal beautiful and tight. Suitable for a variety of packing materials.

7. Intermission charging device, alcohol spraying device and code printer can be mounted.



Photo about Pe film shrink packing machinery:





 SJ-320B/D Pe film shrink packing machinery

Pe film shrink packing machinery

SJ-320B/D Pe film shrink packing machinery

SJ-320B/D Pe film shrink packing machinery

                                                                 SJ-320B/D Pe film shrink packing machinery
