- - Excellent weather resistance, high temperature, humidity and UV resistant EVA Solar Cell Film
- - Excellent material compatibility and matching EVA Solar Cell Film
- - Optimum operability, laminating with wide temperature range and high efficiency EVA Solar Cell Film
- - Excellent anti-PID and anti-snail pattern EVA Solar Cell Film
- - Different types of EVA film such as:
- High transmittance type EVA Solar Cell Film
- Anti-UV type EVA Solar Cell Film
- Anti-PID type EVA Solar Cell Film
- High refractive index type EVA Solar Cell Film
- Anti-snail pattern type EVA Solar Cell Film
- Fast solidifying type will be provided
-
- EVA film with world class quality, and provide more comprehensive solutions for PV modules.
1. EVA Film B601H&B601 for PV Module |
1)EVA film B601H&B601 for PV module encapsulation
Product description
B601H&B601 EVA Solar Cell Film are normal types of Better EVA film, mainly used for theencapsulation of solar panel.
Features
1. Excellent light transmittance. B601H is high transmittance type EVA film while B601 is UV resistant type.
2. Excellent weather resistance, including high temperature humidity and UV resistant.
3. Excellent material compatibility, permanent adhesion with glass, metal and solar back sheet.
4. Optimum operability, easy to store, laminating with high efficiency.
Product types
Model |
Curing type |
Features |
B601H EVA film |
Fast solidifying |
High transmittance |
B601 EVA film |
Fast solidifying |
UV resistance |
Technical Data sheet
Performance index |
Unit |
Test method |
B601H |
B601 |
||
Mode/Application Description |
/ |
/ |
Fast solidifying |
Fast solidifying |
||
High transmittance |
UV resistant |
|||||
Density |
g/cm3 |
GB/T29848-2013 |
0.955 |
0.955 |
||
Size |
Length |
m |
GB/T29848-2013 |
150 |
150 |
|
Width |
mm |
GB/T29848-2013 |
300-2100 |
300-2100 |
||
Thickness |
mm |
GB/T29848-2013 |
0.25-0.80 |
0.25-0.80 |
||
Melting temperature |
℃ |
GB/T29848-2013 |
60-70 |
60-70 |
||
Refractive index |
/ |
ISO 489-1999 |
1.48 |
1.48 |
||
Shrink ratio |
MD |
% |
GB/T29848-2013 |
<3 |
<3 |
|
TD |
% |
GB/T29848-2013 |
<2 |
<2 |
||
Light transmittance |
280~380nm |
% |
GB/T29848-2013 |
>80 |
<30 |
|
380~2200nm |
% |
GB/T29848-2013 |
>91 |
>91 |
||
Peel strength |
EVA/GLASS |
N/cm |
GB/T29848-2013 |
>60 |
>60 |
|
EVA/BACK SHEET |
N/cm |
GB/T29848-2013 |
>80 |
>80 |
||
Degree of crosslinking |
% |
GB/T29848-2013 |
>80 |
>80 |
||
Volume resistivity |
Ωcm |
GB/T29848-2013 |
>2*1014 |
>2*1014 |
||
Hydrothermal aging test |
Yellowing index |
85℃/85RH,1000h |
<2 |
<2 |
||
UV aging test |
Yellowing index |
UV 60KWh |
<2 |
<2 |
||
2. Application of EVA Solar Cell Film Used for PV Module Encapsulation |
As an important part of PV module, BBetter EVA film can protect the capability of solar cell from negative effectand damage of external environment.
BBetter EVA solar cell film can widely used for domestic solar energy,solar streetlamp, solar cell car,outdoor solar, satellite solar and so on.
3. EVA Solar Film PV Modules Certifications |
4. Other Types of EVA Solar Film for PV Modules Encapsulation |
B601W is a white color and high reflecting EVA solar module encapsulating filmused between solar cell and back sheet. It is suitable for encapsulation of thin-film solar and crystalion silicon BJP double class panel.
F806W EVA film has high light reflectivity excellent anti aging and electrical insulating property. The specific high light reflectivity of B601W enhance the solar cell encapsulation’s capacity of gathering light and make the unique appearance to solar panel (beautify the module with unique appearance).
B602G series EVA Solar Cell Film developed by BBetter is new type polyolefin encapsulation material for PV module. With excellent water vapor barrier properties, weather resistance, light transmittance and adhesive ability, it can ensure proper functioning of PV module and give it long acting anti-PID property.
5. EVA Solar Film Workshop |
6. Raw Material and Products’ Test of EVA Solar Film |
7. EVA Solar Film Factory Introduction |
Changzhou BBetter Film Technologies Co., Ltd is established in 2007, the registered capital is 25 Million Dollars, fully invested by China Baixing Group, which ranks top 100 among China's private companies.
Changzhou BBetter Film Technologies Co., Ltd has more than 20 years' experience in manufacturing thermoplastic polymer materials such as EVA, PC, PP, PET, ABS,PETG, and PVC film etc.
Particularly, we emphasize on R&D, we have established pleasant cooperation with CAS, and many 1st level Universities like (HIT)Harbin Institute of Technology and Sichuan University, etc. At the same time, we own Polymeric Laboratory of provincial level.
With extensive experience in the filed of hot melt adhesive and film processing, BBetter successfully developedhigh quality EVA solar cell encapsulating film. With its outstanding product quality, fast delivery, perfect after-sales service system, has quickly become the world’s leading manufacture of EVA solar cell encapsulating film
10. FAQ |
1. Are you manufacturer or Trade Company?
China Baixing Group, founded in 1988, is the largest manufacturing bases of plastic products as
well as one of the TOP100 privately-operated enterprises in China.
2. Sample Rule
We offer you free samples as your requirements. If you are the first time to cooperate with us, the
postage should be paid by you. When you place the order, we will return it back to you. In the next
cooperation, we will be in charge of it.
3. What terms of payment you use?
We accept TT and L/C at sight, other payment terms (D/P, D/A, Western Union, OA, Trade Assurance) can be negotiated.
