Help CenterCE Hydraulic Machine for Crimping Pipe-JK400
Related Products
-
Two Wire Braided Hydraulic Hose Swaging Machine DSG-51AUS$ 1,900 - 2,500MOQ: 1 Set -
Crimping Tool Hydraulic-DSG75US$ 2,000 - 3,000MOQ: 1 Set
-
4 Wire Spiral Hydraulic Hose Swaging Machine DSG-51A From China ManufacturerUS$ 1,900 - 2,500MOQ: 1 Set
-
4 Wire Spiral Hydraulic Hose Crimper-DSG102US$ 1,900 - 2,500MOQ: 1 Set
-
4 Wire Spiral Hydraulic Hose Swager-JK400US$ 1,900 - 2,300MOQ: 1 Set
Specifications
1. Quality assurance2. Superior services
3. Reasonable price
4...Promptly supplies
BRIEF INTRODUCTION:
JK400 type of locking pipe machine is mainly used for locking & press process of a high pressure hose assembly in mechanical engineering and also can lock and press two-way elbow, a large elbow and special shape head.
The machine size is small and compact, the weight is light, the power is great, the noise is low, the operation is easy. The locking & press amount is adjusted by a scale precisely. A complex double bevel eight section mold base equipped with high precision guiding device makes the divided pipe hoop be more uniform appearance after lock and press.
Ⅱ. Main technical characteristics
1. Locking & press scope:Φ6—Φ64mm
2. Maximum locking & press strength:520 tons
3. Scale accuracy: 0.02mm
4. The amount of contraction and expansion:40mm
5. Rated pressure: 25 MPa
6. Motor power: 5.5 KW
7. Pump displacement:14.5L/min (380V)
8. Outer size:710 (L)×500 (W)×810 (H)mm
We can assign our technician for installation and adjustment, also we provide spare parts.
