SK-100Hydraulic Tube Shrinking Machine PLC

Specifications

1) Technical die design and production process.
2) Low noise and small weight.
3) Easy operation or maintenan

The SK-100 type tube locking machine developed by our factory is suitable for hooping processing of the assembly of high pressure rubber tube, fibre pipe and plastic pipe used in industry, agriculture and fluid drive of engineering machinery. It has the advantages of wide hooping range, high precision (adopt PLC control), high degree automation, easy operation and maintenance, etc.

 Main technical character

1. Hooping steel wire rubber tube inner diameter: φ4~φ51IVmm

Industry tube inner diameter: 89mm at the most

1. Scale precision: 0.01mm
2. Power: 4KW
3. Voltage: 380V
4. The maximum hooping force: 252 tons
5. Rotated speed: 1440r/min
6. Oil pump displacement: 10ml/rad
7. Dimension: 858×910×1550(mm)
8. Weight: 800Kg
9. The maximum opening diameter: +68mm
