Online UPS 1K(S)

Name: Online UPS 1K(S)
Brand: Power station
SKU: 157244752
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

Power station

Model Number:

1K(S)

Anhui Arts & Crafts Import & Export Company Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

TIANJING

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name Power station

Model Number 1K(S)

Phase Single Phase

Protection Overvoltage

Weight 13KG

Output Voltage 220VAC

Type On-line

Application Networking

Specifications

1.Zero Transfer time
2.1000 VA online UPS
3.ISO 9001,CE FCC UL
4.one year warranty

Model No	1K / 1KS
VA / W	1KVA/700W
Capacity	phrase	Single phrase with ground
	Voltage	AC 220V
	Voltage range	AC 130V~285V
	Frequency	50Hz
	Power factor	0.97
	Bypass Voltage range	AC 165V ~265V
Output	Phrase	Single phrase with ground
	Voltage	AC 220V
	Power factor	0.7
	Voltage regulation	±3%
	Frequency	AC model	1.Input and output keep same frequency by Input range between 46Hz-54Hz 2.Output frequency will keep at 50HZ,once the input Frequency upon54Hz or Below 46Hz
		Battery Model	50± 0.2 Hz
	Overload capacity	108%±5%<overload≤130%±5%,alarm once more than 25s 130%±5%<overload<150%±5% ;alarm once more than 300ms
	Transfer time	AC:ZERO ms
		Battery :<4ms
	Current Crest ratio	3:1
Battery	Voltage	36VDC
	Numbers of battery	12VDC X 3
	Backup time(25°C)full load	≥5mins
	Recharge time	5 hours to 90%
Dimension	DWH	145220400
Weight	Net W.	1K	1KS
		13Kg	7Kg
Working condition	Operating Temperature	0°C~40°C
	Humidity	20%~90%
	Save Temperature	-15°C~45°C
