Car Camera/Reverse camera for car/rear car camera/backup camera for car-CAM-101M

Main Fuction:

* Without display, standard video connections, with any TFT or LCD screen to connect to the application: GPS, dual-screen tablet with DVD, TV, sun visor screen, etc.;

* To enter the reverse, the radar system into the work automatically, and automatically switch to reverse video, automatic wake-up function;

* Configuration to install a borehole embedded in CMOS camera, infrared night vision function Night vision camera from 6 meters

* Camera optional shape, such as: license plate frame, hanging, etc.

* The camera, waterproof, shockproof, high temperature +80, -30 low-temperature-resistant,anti-jamming

Features descritpion:

* Night vision and weatherproof

* Image Sensor: OV7950, 1/3" COLOR

* Effective Pixels: PAL: 628×586 NTSC: 510×496

* Protection Category: IP67-IP68

* Signal System: NTSC/PAL

* Resolution: 380 TV Lines

* Shutter Speed: 1/50-60~1/15000 second

* S/N Ratio: ≥48db

* Minimum Illumination: < 1.0Lux

* Video Output: 1.0Vp-p, 75 OHM

* Power Supply: DC12V ± 20%

* Current Consumption: ≥80mA

* Operating Temperature: -20°C ~ 65°C

* Lens Angle: 120 Degrees

Car Camera with nigh vision:
