Hospital Service System Phone IP Door Intercom KNZD-03 IP Elevator Telephone Lift Telephone
- T/T L/C D/P D/A
- 7 days
You May Like
-
KNZD-03 Stainless Steel Door Intercom Door Phone Robust Steel Elevator Phone
-
Vandal Resistant Telephone is an Ideal Match for Use in High Traffic Airport Subway Door Phone Robust Steel Elevator Phone
-
KNTECH Professional Emergency Telephone Auto Dial System Hotel Emergency Convenient Phone Hospital Public Service Phone
-
Rugged Paging Equipment of Network Industrial Intercome
-
KNZD-41 Emergency Telephone Fire Alarm System Wireless Call Bell System Handset Sos Phone Addressable Fire Alarm
-
Sos Phone Addressable Fire Alarm KNZD-41 Emergency Telephone Fire Alarm System
Product Details
| Place of Origin | China |
Product Description
KNZD-03 Swireless telephone ubway door phone with intercom system telephone
Specifications
As Public telephone for indoor or outdoor, Taxi or bus stands or station, Highway call box, Railway, metro, ATM machines side, Tunnel, Port, Dock, Mines, Generation facilities...
A good ideal telephone for use in wet or corrosive atmospheres
DTMF(Dual Tone Multi Frequency)
Standard and SMART Analogue and VoIP-SIP options available
Matching with most PABX, PBX and PAX systems
Main Features
1. Main body with whole stainless steel body, solid and temperature bearable
2. Handset free, loudspeaker,
3. Resume lightning proof protection automatically standard to ITU-T K21
4. Waterproof grade is IP65(can improve to IP67)
5. The metal shell is provided with grounding connection device and is absolutely insulated with inner circuit and electric , then has the effect of electromagnetism shield.
6. Support hotline call, can realize ring off automatically if the other side close.
7. Totally adopt SMTC craftwork keep very good quality.
8. The design is super thin and smart. Embed style and hanging style can be chosen.
9. Every call is limited(set by five minutes), auto ring off if time exceeded. (Optional)
10.The telephone has passed the certificate of ISO9000(2000)
11.Size can according customer's request.
Main Parts
stainless steel body
PCB Board
Button
MIC
Technical indexes
1. Applicable for various types of SPC exchange and dispatching exchange system with feeding voltage of 48-69V.
2. Ambient temperature: -30 ~ +60 degreeRelative humidity: 10%~95%Atmospheric pressure: 86~106Kpa Circumstance noise: less than 60dB(A)
3. Sound level of ringing: over 70dB(A).
4. Standard frequency: low frequency group: 697. 770. 852. 941Hz,
high frequency group: 1209, 1336, 1477Hz, frequency deviation: -1.5%~+1.5%
If service line is a 3Km signal-level:
Standard frequency: low frequency group: -12dB~-6dB, high frequency group: -10dB~-4dB, level difference between low and high frequency of compound signal: 1dB~3dB, the total distortion caused by intermodulation of harmonic wave is lower than the basic level by at least 20dB.
5. Call transmission index: (5KM)SLR<12, RLR<-1, STMR>10, output impedance is 600 Ohm.
6. Super strong function is available for dialing 12 groups of numbers stored in the memory (maximum length of each number is16 digits)
The device pass all the latest European/UK standards for EMC and US FCC, telephony,
waterproofing IP66, and lightening protection together with offering the level of performance and reliability demanded in such an environment.
