KNSP-08 Loudspeaker Voice Broadcasting Intustrial Telephone Outdoor Phone Ip67 Waterproof Telephone

KNSP-08 Loudspeaker voice broadcasting intustrial telephone outdoor phone ip67 waterproof telephone

Specifications

As Public telephone for indoor or outdoor, Taxi or bus stands or station, Highway call box, Railway, metro, ATM machines side, Tunnel, Port, Dock, Mines, Generation facilities...

A good ideal telephone for use in wet or corrosive atmospheres

DTMF(Dual Tone Multi Frequency)

Standard and SMART Analogue and VoIP-SIP options available

Matching with most PABX, PBX and PAX systems

Main Features

1. Robust aluminium alloy die-cast body, Vandal resistant and tamper-resistant hardware, simple installation.

2. 10 groups speed dial telephone number.

3. analog and VOIP version optional.

4. Door cover: orient automatically and good self - closing, convenient for use.

5. Weather resistant to IP67 standard, service temperature range from -30 degree to +75 degree

6. Magnetic reed hook-switch

7. telephone line powered or POE powered / AC power supply from 110V~240V.

8. Lightening protection to ITU-T recommendation K.21

9. Hearing Aid compatible receiver, Noise canceling microphone.

10. Phone integrity wiring to enable the telephone system to check if the telephone unit is still operational.

11. All of the components including keypad, buzzer, circuit board and cabinet are designed to be multi - layer waterproof and dust - proof which is up to Class III grade. The whole machine is up to national standard GB4208-93 IP 66.

12. Phone is provided with high stability, high anti-jamming capability standard to GB/T 15279-94.

13.when the call is coming , the ring tone will come out from the speaker , after ring 5 times, if no one answer the phone, the caller's voice will come out from speaker to ask somebody to answer the phone , and the the called party pick up the phone to talk with caller.

Main Parts

Robust aluminium alloy die-cast body

Door

PCB Board

Dial pad

Handset & hook

Telephone line

Loudspeaker

Main Features

1. Robust aluminium alloy die-cast body, Vandal resistant and tamper-resistant hardware, simple installation.

2. 10 groups speed dial telephone number.

3. analog and VOIP version optional.

4. Door cover: orient automatically and good self - closing, convenient for use.

5. Weather resistant to IP67 standard, service temperature range from -30 degree to +75 degree

6. Magnetic reed hook-switch

7. telephone line powered or POE powered / AC power supply from 110V~240V.

8. Lightening protection to ITU-T recommendation K.21

9. Hearing Aid compatible receiver, Noise canceling microphone.

10. Phone integrity wiring to enable the telephone system to check if the telephone unit is still operational.

11. All of the components including keypad, buzzer, circuit board and cabinet are designed to be multi - layer waterproof and dust - proof which is up to Class III grade. The whole machine is up to national standard GB4208-93 IP 66.

12. Phone is provided with high stability, high anti-jamming capability standard to GB/T 15279-94.

13.when the call is coming , the ring tone will come out from the speaker , after ring 5 times, if no one answer the phone, the caller's voice will come out from speaker to ask somebody to answer the phone , and the the called party pick up the phone to talk with caller.

The device pass all the latest European/UK standards for EMC and US FCC, telephony,

waterproofing IP66, and lightening protection together with offering the level of performance and reliability demanded in such an environment.
